參數資料
| 型號： | NL27WZ86US |
| 廠商： | ON SEMICONDUCTOR |
| 元件分類： | 通用總線功能 |
| 英文描述： | Dual 2-Input Exclusive-OR Gate |
| 中文描述： | 27WZ SERIES, DUAL 2-INPUT XOR GATE, PDSO8 |
| 封裝： | US-8 |
| 文件頁數： | 1/6頁 |
| 文件大小： | 65K |
| 代理商： | NL27WZ86US |
Semiconductor Components Industries, LLC, 2004
March, 2004 Rev. 2
1
Publication Order Number:
NL27WZ86/D
NL27WZ86
Dual 2Input ExclusiveOR
Gate
The NL27WZ86 is a high performance dual 2input ExclusiveOR
Gate operating from a 1.65 V to 5.5 V supply.
Extremely High Speed: t
PD
2.4 ns (typical) at V
CC
= 5.0 V
Designed for 1.65 V to 5.5 V V
CC
Operation
Over Voltage Tolerant Inputs and Outputs
LVTTL Compatible Interface Capability With 5.0 V TTL Logic
with V
CC
= 3.0 V
LVCMOS Compatible
24 mA Balanced Output Sink and Source Capability
Near Zero Static Supply Current Substantially Reduces System
Power Requirements
Replacement for NC7WZ86
Figure 1.
A2
B2
Y2
Figure 1. Pinout
(Top View)
Figure 2. Logic Symbol
= 1
Y1
A1
B1
V
CC
A1
B1
GND
1
2
3
8
7
6
4
5
Y2
Y1
B2
A2
PIN ASSIGNMENT
Pin
1
2
3
4
5
6
7
8
Function
A1
B1
Y2
GND
A2
B2
Y1
V
CC
Input
FUNCTION TABLE
B
L
H
L
H
Output
Y = A + B
Y
L
H
H
L
A
L
L
H
H
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
ORDERING INFORMATION
MARKING
DIAGRAM
US8
US SUFFIX
CASE 493
8
1
1
8
L8
D
D = Date Code
http://onsemi.com
