Semiconductor Components Industries, LLC, 2007
February, 2007
Rev. 10
1
Publication Order Number:
NL7SZ19/D
NL7SZ19
1to2 Decoder/
Demultiplexer
The NL7SZ19 is a 1
to
2 decoder. When the output enable (E) is
Low, the device passes data at input A to outputs Y0 (true) and Y1
(complement). The NL7SZ19 can also be used as a 1
to
2
demultiplexer. As a demultiplexer, data at input E is routed to either
Y0 or Y1 depending on the state of A. The device operates over the
voltage range from 1.65 V to 5.5 V. The device is fabricated in
sub
micron CMOS for high speed and fast decode times. Both inputs
and outputs are in high impedance state, when supply voltage is
powered down. Both inputs are tolerant of voltages up to 5.5 V,
regardless of operating voltage. This device is suitable for low power
decoding in a variety of applications.
Features
High
Speed Propagation Delay:
t
PD
2.7 nS (Typ), Load 50 pF @ 5.0 V
32 mA Output Drive Capability @ 5.0 V
Power Down Impedance: Inputs/Outputs in High
Z
Broad V
CC
Operating Range: 1.65 V to 5.5 V
Surface Mount Technology: SC
70, 6
Lead and UDFN6 Packaging
OVT* on I/Os
Pb
Free Package is Available
Typical Applications
Cell Phones
PDAs
Digital Cameras
Video Cameras
Important Information
ESD Protection: Human Body Model >2000 V
Latchup Max Rating: 300 mA
Pin to Pin Compatible with NC7SZ19
1
2
3
6
5
4
GND
A
E
V
CC
Y
0
Y
1
(TOP VIEW)
Figure 1. Pinout
*
O
ver
V
oltage
T
olerance (OVT) enables input and output pins to function outside
(higher) of their operating voltages, with no damage to the devices or to signal
integrity.
MARKING
DIAGRAM
SOT
363/SC70
6/SC
88
DF SUFFIX
CASE 419B
1
6
LE, U
M
= Device Marking
= Date Code*
= Pb
Free Package
http://onsemi.com
PIN/FUNCTION TABLE
Pin
A
E
Y
0
Y
1
Function Description
Address
Output Enable
Output 0
Output 1
TRUTH TABLE
L
L
H
H
E
Y
0
= A + E
L
H
H
L
A
L
H
H
H
Y
1
= A + E
H
L
H
H
LE M
1
6
See detailed ordering and shipping information in the package
dimensions section on page 2 of this data sheet.
ORDERING INFORMATION
*Date Code orientation may vary depending
upon manufacturing location.
(Note: Microdot may be in either location)
U M
1
UDFN6
MU SUFFIX
CASE 517AA
Output 0
Output 1
As Decoder
As Demultiplexer
Select
Data
