Semiconductor Components Industries, LLC, 2004
February, 2004 Rev. 6
1
Publication Order Number:
NLAS323/D
NLAS323
Dual SPST Analog Switch,
Low Voltage, Single Supply
The NLAS323 is a dual SPST (Single Pole, Single Throw) switch,
similar to 1/2 a standard 4066. The device permits the independent
selection of 2 analog/digital signals. Available in the US8 package.
The use of advanced 0.6
micron CMOS process, improves the R
ON
resistance considerably compared to older higher voltage
technologies.
On Resistance is 20 Typical at 5.0 V
Matching is < 1.0 Between Sections
2.0 to 6.0 V Operating Range
Ultra Low < 5.0 pC Charge Injection
Ultra Low Leakage < 1.0 nA at 5.0 V, 25 C
Wide Bandwidth > 200 MHz, 3.0 dB
2000 V ESD (Human Body Model)
Ron Flatness
6.0 at 5.0 V
US8 Package
Independent, Positive Enable
PbFree Package is Available*
V
CC
NO1
COM1
GND
Figure 1. Pinout
IN2
NO2
1
2
3
8
7
6
COM2
IN1
4
5
See detailed ordering and shipping information in the package
dimensions section on page 8 of this data sheet.
ORDERING INFORMATION
MARKING
DIAGRAM
PIN ASSIGNMENT
1
2
3
IN2
NO1
GND
4
5
COM1
IN1
6
FUNCTION TABLE
L
H
On/Off
Enable Input
State of
Analog Switch
Off
On
7
8
V
CC
COM2
NO2
US8
US SUFFIX
CASE 493
8
1
1
8
A4
D
A4 = Device Code
D = Date Code
http://onsemi.com
*For additional information on our PbFree strategy
and soldering details, please download the
ON Semiconductor Soldering and Mounting
Techniques Reference Manual, SOLDERRM/D.
