All specifications are subject to change without notice.
Specifications which provide more details for the proper and safe use of the described product are available upon request.
Inductors
For Power Line
SMD
NLC Series NLC3225 Type
FEATURES
The NLC series feature low DC resistance and high current
handling capacities, making them ideal for power supply line
applications.
They are available in form factors ranging from 2520 to 5650.
APPLICATIONS
Portable telephones, personal computers, hard disk drives, and
other electronic equipment.
SPECIFICATIONS
Operating temperature range
Storage temperature range
RECOMMENDED SOLDERING CONDITIONS
REFLOW SOLDERING
FLOW SOLDERING
IRON SOLDERING
Perform soldering at 250°C on 30W max. within 5 seconds.
VAPOR-PHASING
FLUX AND CLEANING
Rosin-based flux is recommended.
Cleaning Conditions
Solvent
Chlorine-based solvent
(Do not use acid or alkali solvents.)
Time
2min max.
PRODUCT IDENTIFICATION
(1) Series name
(2) Dimensions L
252018
322522
453232
565050
×
W
×
T
(3) Packaging style
T
(4) Inductance value
1R0
330
(5) Inductance tolerance
K
M
PACKAGING STYLE AND QUANTITIES
Packaging style
Type
Taping
NLC252018T
NLC322522T
NLC453232T
NLC565050T
–20 to +85°C
–40 to +85°C [Unit of products]
30s max.
Preheating: 120s
10s max.
100°C
200°C
230°C
150°C
Natural
cooling
Time(s)
Preheating: 120s
10s max.
100°C
260°C
150°C
Natural
cooling
Time(s)
Preheating: 120s
10s max.
100°C
215°C
150°C
220°C
Natural
cooling
30s max.
Time(s)
2.5
3.2
4.5
5.6
×
×
×
×
2.0
2.5
3.2
5.0
×
×
×
×
1.8mm
2.2mm
3.2mm
5.0mm
Taping(reel)
1
33
μ
H
μ
H
±10%
±20%
Quantity
2000 pieces/reel
2000 pieces/reel
500 pieces/reel
400 pieces/reel
NLC
(1)
252018
(2)
T-
(3)
2R2
(4)
M
(5)
