HYBRID IC
M57182N-416
UNINSULATED DC-DC CONVERTER
INTERNAL STRUCTURE FIGURE
4
THE CAUTIONS ON USE
1. About an over-current and a load short circuit
Although this hybrid IC has prepared protection circuit for an over-current, please use a fuse, taking the safety of a product into
consideration.
2 About parts placement
Please place input/output capacitors near this hybrid IC. And Place a coil on the opposite side of capacitors as follows
3. The capacitor for smoothing output voltage
Please use electrolytic capacitor of output side with low impedance.
4. Coil
Please use power inductors with good performance of DC superimposition.
(We used C13 – FR –102: made in MITSUMI ELECTRIC CO., LTD.)
Glass epoxy substrate
Semiconductor
Tip capacitor
Tip resistor
Epoxy resin
Lead frames (Soft iron)
Input capacitor
Coil
Output capacitor
M57182N-416
