PRODUCT SPECIFICATION
Single chip 2.4 GHz Transmitter
Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989
Revision: 2.0
Page 1 of 31
April 2005
FEATURES
True single chip GFSK transmitter in a
small 16-pin package (QFN16 4x4)
Adjustable output power up to 0dBm
Data rate 0 to 1Mbps
Low Bill of Material
Multi Channel operation
128 channels
Support frequency hopping
Channel switching time <200
μ
s.
Power supply range: 1.9 to 3.6 V
CRC computation
ShockBurst mode for ultra-low power
operation
Low supply current, typical 10mA peak
@ -5dBm output power
100% RF tested
World wide use
GENERAL DESCRIPTION
nRF2402/nRF2402G is a single-chip radio transmitter for the world wide 2.4 - 2.5 GHz ISM
band. The transmitter consists of a fully integrated frequency synthesizer, a power amplifier,
a crystal oscillator and a modulator. Output power and frequency channel is easily
programmable by use of the 3-wire interface. Current consumption is very low, only 10 mA
at an output power of -5dBm. Built-in ShockBurst and Power Down modes makes power
saving easily realizable.
QUICK REFERENCE DATA
Parameter
Minimum supply voltage
Maximum output power
Maximum GFSK data rate
Supply current GFSK transmitter @ -5dBm output power
Supply current in Power Down mode
APPLICATIONS
Wireless mouse, keyboard, joystick
Keyless entry
Wireless data communication
Alarm and security systems
Home Automation
Remote control
Surveillance
Automotive
Telemetry
Intelligent sports equipment
Industrial sensors
Toys
Value
1.9
0
1000
10
200
Unit
V
dBm
kbps
mA
n
Α
Table 1 nRF2402/nRF2402G quick reference data
Type Number
NRF2402
NRF2402G
Description
16 pin QFN 4x4, punch/saw
16 pin QFN 4x4, punch, green
Version
A
A
Table 2 nRF2402/nRF2402G ordering information
nRF2402
nRF2402G
