5200 St. Patrick St., Montreal
Que., H4E 4N9, Canada
Tel: 514-768-8000
Fax: 514-768-8889
The Old Railway, Princes Street
Ulverston, Cumbria, LA12 7NQ, UK
Tel: 01 229 581 551
Fax: 01 229 581 554
QF-84
NSL-26
Optocouplers
Features
Hermetic photocell
Compact, moisture resistant package
Low LED current
Passive resistance output
Description
This optocoupler consists of an LED input optically
coupled to a hermetic photocell. The photocell
resistance is high when the LED current is “off” and low
when the LED current is “on”.
Absolute Maximum Ratings
Storage Temperature
Operating Temperature
Soldering Temperature (1)
Isolation Voltage (peak)
-40 to +75
°
C
-40 to +75
°
C
260
°
C
2000V
Notes:
1. >2 mm from case for <5 sec.
2. Derate linearly to 0 at 75
°
C
3. The Rise Time, T
R
, is the time required for the dark
to light change in conductance to reach 63% of its
final value.
Photocell
LED
Color
dot
Dimensions in mm.
Lead spacing tolerance: +/- 0.13
Cathode
short lead
0.38-0.54
on all leads
+
-
10.4 - 10.9
25.4 min.
12.7 min.
5.08
8.2 - 9.4
2.54
LED
Photocell
Circuit Schematic
+
-
Electrical Characteristics
(T
A
=25
°
C unless otherwise noted)
Symbol Parameter
LED
I
F
Forward Current
V
F
Forward Voltage
I
R
Reverse Current
Cell
V
C
Maximum Cell Voltage
P
D
Power Dissipation
Coupled
R
ON
On Resistance
R
OFF
Off Resistance
T
R
Rise Time
T
F
Decay Time
Cell Temp. Coefficient
Specifications subject to change without notice
Min
Typ
Max
Units Test Conditions
40
2.5
3.0
mA
V
μ
A
I
F
= 16 mA
V
R
= 4V
120
200
V
(Peak AC or DC)
(2)
mW
2
K
M
msec Time to 63% of final conductance @ I
F
=16mA (3)
msec Time to 100K
after removal of I
F
=16mA
%/
°
C I
F
> 5 mA
I
F
= 16 mA
10 sec after I
F
= 0, 5Vdc on cell.
10
3.5
20
0.7
103064 REV 1
