PCA8565
Real time clock/calender
Rev. 01 — 31 March 2003
Product data
1.
General description
The PCA8565 is a CMOS real time clock/calendar optimized for low power
consumption. A programmable clock output, interrupt output and voltage-low detector
are also provided. All address and data are transferred serially via a two-line
bidirectional I
2
C-bus. Maximum bus speed is 400 kbit/s. The built-in word address
register is incremented automatically after each written or read data byte.
2.
Features
I
Provides year, month, day, weekday, hours, minutes and seconds based on
32.768 kHz quartz crystal
I
Century flag
I
Clock operating voltage: 1.8 to 5.5 V
I
Extended operating temperature range:
40 to +125
°
C
I
Low backup current; typical 0.5
μ
A at V
DD
= 3.0 V and T
amb
= 25
°
C
I
400 kHz two-wire I
2
C-bus interface (at V
DD
= 1.8 to 5.5 V)
I
Programmable clock output for peripheral devices (32.768 kHz, 1024 Hz,
32 Hz and 1 Hz)
I
Alarm and timer functions
I
Integrated oscillator capacitor
I
Internal power-on reset
I
I
2
C-bus slave address: read A3H and write A2H
I
Open-drain interrupt pin.
3.
Applications
I
Automotive
I
Industrial
I
Other applications that require a wide operating temperature range.
4.
Quick reference data
Table 1:
Symbol
V
DD
Quick reference data
Parameter
supply voltage
Conditions
I
2
C-bus active; f
SCL
= 400 kHz;
T
amb
=
40 to +125
°
C
f
SCL
= 400 kHz
Min
1.8
Typ
-
Max
5.5
Unit
V
I
DD
T
amb
supply current
ambient temperature
-
40
-
-
820
+
125
μ
A
°
C
