Preliminary Data
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to
change without notice.
January 2007
Rev 1
1/47
47
PM6675
High efficiency step-down controller
with embedded 2A LDO regulator
Features switching
■ Switching section
– 4.5V to 28V input voltage range
– 0.6V, ±1% voltage reference
– Selectable 1.5V fixed output voltage
– Adjustable 0.6V to 3.3V output voltage
– 1.237V ±1% reference voltage available
– Very fast load transient response using
constant on-time control loop
–No RSENSE current sensing using low side
MOSFETs' RDS(ON)
– Negative current limit
– Latched OVP and UVP
– Soft start internally fixed at 3ms
– Selectable pulse skipping at light load
– Selectable No-Audible (33KHz) pulse skip
mode
– Ceramic output capacitors supported
– Output voltage ripple compensation
– Output soft-end
■ LDO regulator section
– Adjustable 0.6V to 3.3V output voltage
– Selectable ±1Apk or ±2Apk current limit
– Dedicated Power-Good signal
– Ceramic output capacitors supported
– Output soft-end
Applications
■ Notebook computers
■ Graphic cards
■ Embedded computers
Description
The PM6675 device consists of a single high
efficiency step-down controller and an
independent Low Drop-Out (LDO) linear
regulator.
The Constant On-Time (COT) architecture
assures fast transient response supporting both
electrolytic and ceramic output capacitors. An
embedded integrator control loop compensates
the DC voltage error due to the output ripple.
A selectable low-consumption mode allows the
highest efficiency over a wide range of load
conditions. The low-noise mode sets the minimum
switching frequency to 33kHz for audio-sensitive
applications.
The LDO linear regulator can sink and source up
to 2Apk. Two fixed current limits (±1A-±2A) can be
chosen.
An active Soft-End is independently performed on
both the switching and the linear regulators
outputs when disabled.
VFQFPN-24 4x4
Order codes
Part number
Package
Packaging
PM6675
VFQFPN-24 4x4 (Exposed Pad)
Tube
Obsolete
Product(s)
- Obsolete
Product(s)
Obsolete
Product(s)
- Obsolete
Product(s)
