Product # PQ50050HPB50
Phone 1-888-567-9596
www.synqor.com
Doc.# 005-0005487 Rev. A
03/18/10
Page 1
PQ50050HPB50
Protection Features
Mechanical Features
Page No.
MECHANICAL DIAGRAM (base-plated)......................... 2
Electrical Characteristics................................... 3
Standards and Qualifications................................ 5
Figures ............................................... 7
Application Section ..................................... 10
Ordering Information .................................... 14
Control Features
Contents
Operational Features
Safety Features
Industry standard pin-out configuration
Size: 2.3” x 2.4” (58.4 x 61.0mm)
Total height only 0.50” (12.7mm)
Total weight: 4.3oz. (123 grams)
Ultra-high efficiency, 92% at full rated load
Delivers up to 250W of output power with minimal derating
Operating input voltage range: 44-52V
Fixed frequency switching provides predictable EMI performance
Input under-voltage lockout disables converter at low input
voltage conditions
Output current limit and short circuit protection
Active back bias limit prevents damage to converter from external load
induced pre-bias
Output over-voltage protection
Thermal shutdown
On/Off control referenced to input side
(positive and negative logic options are available)
Remote sense for the output voltage compensates for output
distribution drops
Output voltage trim permits custom voltages and voltage margining
Output voltage trim range of -20%, +10%
The PQ50050HPB50 PowerQor Peta half-
brick converter is a next-generation, board-
mountable, isolated, fixed switching frequency
DC/DC converter that uses synchronous
rectification
to
achieve
extremely
high
conversion efficiency.The Peta series converters
offer industry leading output current for a
standard half-brick module. RoHS compliant (see
last page).
Pending
2000V, 30MΩ input-to-output isolation
UL 60950-1 recognized (US & Canada), basic insulation rating
TUV certified to EN60950-1
Meets UL94V-0 flammability requirements
