參數資料
| 型號： | QEE213 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 紅外LED |
| 英文描述： | PLASTIC INFRARED LIGHT EMITTING DIODE |
| 中文描述： | 1.52 mm, 1 ELEMENT, INFRARED LED, 940 nm |
| 封裝： | PLASTIC PACKAGE-2 |
| 文件頁數： | 2/4頁 |
| 文件大小： | 281K |
| 代理商： | QEE213 |
Parameter
Operating Temperature
Storage Temperature
Soldering Temperature (Iron)
(2,3,4)
Soldering Temperature (Flow)
(2,3)
Continuous Forward Current
Reverse Voltage
Peak Forward Current
(5)
Power Dissipation
(1)
Symbol
T
OPR
T
STG
T
SOL-I
T
SOL-F
I
F
V
R
I
FP
P
D
Rating
-40 to + 100
-40 to + 100
240 for 5 sec
260 for 10 sec
100
5
1
100
Unit
°
C
°
C
°
C
°
C
mA
V
A
mW
PLASTIC INFRARED
LIGHT EMITTING DIODE
QEE213
Parameter
Test Conditions
Symbol
Min
Typ
Max
Units
Peak Emission Wavelength
Emission Angle
Forward Voltage
Reverse Current
Radiant Intensity
Rise Time
Fall Time
I
F
= 100 mA
I
F
= 100 mA
I
F
= 100 mA, tp = 20 ms
V
R
= 5 V
I
F
= 100 mA, tp = 20 ms
I
F
= 100 mA
tp = 100 μs, T = 10 mS
l
P
U
V
F
I
R
I
e
t
r
t
f
—
—
—
—
2
—
—
940
±25
—
—
—
1
1
—
—
1.5
10
—
—
—
nm
Deg.
V
μA
mW/sr
μs
ELECTRICAL / OPTICAL CHARACTERISTICS
(T
A
=25
°
C)
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25
°
C unless otherwise specified)
NOTES
1. Derate power dissipation linearly 2.67 mW/
°
C above 25
°
C.
2. RMA flux is recommended.
3. Methanol or isopropyl alcohols are recommended as cleaning agents.
4. Soldering iron
1/16
”
(1.6 mm) minimum from housing.
5. Pulse conditions: tp = 100 μs, T = 10 ms.
www.fairchildsemi.com
2 OF 4
9/18/01
DS300239
