Electronic control gear
QUICKTRONIC PROFESSIONAL, two-lamp version
QTP 2x36/230-240
Page 1
l
b
a
h
b
h
Reference :
Mains voltage [V] :
QTP 2x36/230-240
for lamp :
2x L 36 (L 38)
230/240
Permissible voltage fluctuations
[V] :
198 - 264
Permissible battery voltage [V] :
Mains frequency [Hz] :
Mains current at 230 V/240 V/ A :
System wattage at 230 V/240 V
[W] :
Luminous flux [lm] :
Radio interference suppression :
154 - 276
Lamp start :
Warm start within 2 s
0/50 - 60
Operating frequency [kHz] :
30
0,31
Power factor [c] :
approx. 0,98
70 (70)
Lamp wattage at 230 V/240 V [W]
:
64 (64)
2 x 3200
Temperature range [°C] :
-25 - +50
to.DIN VDE 0875/CISPR 15/EN
55015
Harmonics :
to DIN VDE 0712 Part 23/IEC
929/IEC 555-2/EN 60929
Immunity :
Width b [mm] :
Distance between holes a [mm] :
Weight [g] :
to EN 61547
Length l [mm] :
423
30
Height h [mm] :
30
415
Standard pack [pcs] :
20
415
EAN 40 50300 :
479217
Fully electronic high-frequency control gear for fluorescent lamps represent a major advance in low-maintenance, energy-saving lighting.
Comfort:
- Flicker-free ignition, flicker-free light, no distracting hum
- No flashing or flickering of faulty lamps
Economy:
- 27% lower power consumption
- Lower maintenance costs since there are fewer lamps and no starters to replace
- QUICKTRONIC SHORT, QUICKTRONIC DE LUXE DIMMABLE for applications with more than 10 switching operations a day
- Reduced load on air conditioning systems
