Set your site on PICOR at www.picorpower.com
PRELIMINARY
Data Sheet
QuietPower
Output Ripple Attenuation SiP
Vicor Corp.
Tel: 800-735-6200, 978-470-2900 Fax: 978-475-6715
QPO-1 Data Sheet
Page 1 of 8
Parameter
+In to –In
Rating
33
Unit
Vdc
Notes
Continuous
+In to –In
40
Vdc
100ms
Load current
15
A
Continuous
Maximum power dissipation
4
W
Operating temperature
-20 to +85
°C
Ambient
Package thermal resistance
50
°C/W
Free Air
Package thermal resistance
TBD
°C/W
Optimum heat sinking
Storage temperature
-40 to +125
°C
Features
>20dB PARD attenuation from
50Hz to 500kHz
Supports point of load regulation
Peak ripple detector optimizes
performance automatically
Significantly improves load
transient response
Efficiency up to 98%
User selectable performance
optimization
3-30Vdc operating range
10A rating
Product Highlights
Picor’s QPO-1 output ripple attenuator
System-in-a-Package (SiP) provides active
filtering to achieve greater than 20 dB
attenuation of periodic and random deviation
(PARD) over the frequency range of
50Hz to 500kHz.
The QPO-1 operates over a voltage range
of 3 to 30Vdc and is compatible with most
switching power supplies and converters.
The load is regulated by using remote
sensing or a reference type trim adjustment
feature as is commonly found on most
power supplies.
The QPO-1’s closed loop architecture
greatly improves load transient response
while ensuring steady-state precise point of
load voltage regulation. The QPO-1 is
available in surface mountable Land Grid
and Ball Grid Array terminations.
TM
Shown actual size:
1.0 x 1.0 x 0.2 in
25 x 25 x 5 mm
Absolute Maximum Ratings
Exceeding these parameters may result in permanent damage to the product
Part Numbering
Patents Pending
Q P O - 1 L
L = Land Grid Array
B = Ball Grid Array
