S101S15V/S101S16V
S201S15V/S201S16V
SIP Type SSR with Built-in
Snubber Circuit
s Outline Dimensions
(Unit : mm )
s Features
s Applications
2. Isolation voltage between input and output
Viso
3. Built-in zero-cross circuit
(S101S16V/ S201S16V)
4. Built-in snubber circuit
1. Air conditioners
2. OA equipment
IT : MAX. 3Arms
s Model Line-ups
s Absolute Maximum Ratings
(Ta = 25C )
For 100V lines
For 200V lines
No built-in
zero-cross circuit
S101S15V
S201S15V
Built-in zero-cross
circuit
S101S16V
S201S16V
( 36.0
)
(7.62)(2.54)
(1.4)
+
Internal connection diagram
12
3
4
12
3 4
12
3 4
3 Input ( + )
Zero-cross
circuit
1 Output (Triac T2 )
2 Output (Triac T1 )
1 Output (Triac T2 )
2 Output (Triac T1 )
-
4 Input ( - )
Common to Pin No.1
connected
S101S15V/S201S15V
S101S16V/S201S16V
Parameter
Symbol
Unit
100V line 200V line
Input
Forward current
IF
50
mA
Reverse current
V R
6V
Output
RMS ON-state current
IT
3 ( Tc<=100C)
A rms
*1 Peak one cycle surge
current
I surge
30
A
Repetitive peak OFF-
state voltage
V DRM 400
600
V
ON-state current
40
Operating frequency
f
45 to 65
H Z
Operating temperature
T opr
- 20 to + 80
C
Storage temperature
T stg
- 30 to + 100
C
*2 Isolation voltage
V iso
3.0
*3
Soldering temperature
T sol
260
C
S101S15V/S101S16V/S201S15V/S201S16V
1. High radiation resin mold package
Ratings
Critical rate of rise of
*1 60H Z sine wave, Tj = 25C
Isolation voltage measuring method:
( 1) Dielectric withstand tester, with zero-cross circuit shall be used.
( 2) The waveform of applied voltage shall be sine wave.
( 3) It shall be applied voltage between input and output.
( Input and output shall be short-circuited respectively)
*3 For 10 seconds
A/
s
data books, etc. Contact SHARP in order to obtain the latest version of the device specification sheets before using any SHARP's device.”
“ In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that occur in equipment using any of SHARP's devices, shown in catalogs,
g May not be externally
A Model No,
B
S101S15V
S101S16V
S201S15V
S201S16V
3A125VAC
3A265VAC
g
(5.08)
A
dIT /dt
*2 AC 60Hz for 1 minute, 40 to 60% RH
5. Recognized by UL, file No. E94758
Approved by CSA, file No. LR63705
B
: 3 000 Vrms
18.5
± 0.2
16.4
± 0.3
φ 3.2 ± 0.2
3.2
±
0.2
5.5
± 0.2
5.0
±
0.3
19.6
±
0.2
4 - 1.1 ± 0.2
4 - 1.25 ± 0.3
4 - 0.8 ± 0.2
4.2
MAX.
11.2
MIN.
0.6
± 0.1
kV rms
