4. SAWW7D0A, SAWW7E0A
4-1 Electro-Optical characteristics at 220V/230V Ta=25C
4-2 Absolute Maximum Ratings
Characteristics of A7 (SAWX7X0A)
Parameter
Symbol
Value
Unit
Min
Typ
Max
Luminous Flux [1]
Ф
V
[2]
-
190
-
lm
Correlated Color Temperature [3]
CCT
-
3000
-
K
CRI
Ra
-
80
-
Operating Current
Iopt
-
20
-
mA
[RMS]
Operating Voltage
vopt
220/230
V[RMS]
Power Dissipation
PD
3.3
W
Operating Frequency
Freq
50 / 60
Hz
Thermal resistance
Rth
4.0
C/W
View Angle
2
Θ 1/2
130
deg.
* Notes :
[1] Acriche series maintains a tolerance of ±10% on flux and power measurements.
[2]
Ф
V is the total luminous flux output as measured with an integrated sphere.
[3] Correlated Color Temperature is derived from the CIE 1931 Chromaticity diagram.
CCT ±5% tester tolerance
[4] ‘Operating Voltage' doesn't indicate the maximum voltage which customers use, but it
means tolerable voltage according to the voltage variation rate by one's country.
It is recommended that the temperature of solder pad should be below 70
℃.
Parameter
Symbol
Value
Unit
Operating Voltage
vopt [4]
253/265
V [RMS]
Power Dissipation
PD
6.4
W
Junction Temperature
Tj
125
C
Operating Temperature
Topr
-40 ~ +85
C
Storage Temperature
Tstg
-40 ~ +120
C
ESD Sensitivity
-
± 6,000V HBM
-
