| 型號： | SBBGMDBGA99W |
| 廠商： | SUNLED COMPANY LTD |
| 元件分類： | LED |
| 英文描述： | T1-1/2 TRIPLE COLOR LED, RED/GREEN/BLUE, 4 mm |
| 封裝： | 6 X 5 MM, ROHS COMPLIANT PACKAGE-6 |
| 文件頁數： | 1/6頁 |
| 文件大小： | 249K |
| 代理商： | SBBGMDBGA99W |
www.SunLED.com
Published Date : FEB 27,2008
Drawing No : SDSA6408
V1
Checked : B.L.LIU
P.1/6
Part Number:
SBBGMDBGA99W
5.0mm x 6.0mm FULL COLOR LED LAMP
Part
Number
Emitting
Color
Emitting
Material
Lens-color
Luminous
Intensity
(IF=30mA *50mA)
mcd
Wavelength
nm
λ P
Viewing
Angle
2
θ 1/2
min.
typ.
SBBGMDBGA99W
Blue
InGaN
Water Clear
180
297
468
Red
InGaAlP
*380
*497
640
100°
Green
InGaN
180
347
520
BBG
(InGaN)
Unit
Forward Voltage (Typ.)
(IF=20mA)
VF
3.2
V
Forward Voltage (Max.)
(IF=20mA)
VF
4.0
V
Reverse Current (Max.)
(VR=5V)
IR
10
uA
Wavelength of Peak
Emission (Typ.)
(IF=20mA)
λ P
468
nm
Wavelength of Dominant
Emission (Typ.)
(IF=20mA)
λ D
470
nm
Spectral Line Full Width
At Half-Maximum (Typ.)
(IF=20mA)
Δλ
21
nm
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
100
pF
Operating Characteristics
(TA=25°C)
MD
(InGaAlP)
1.9
2.5
10
640
628
27
45
BGA
(InGaN)
3.2
4.0
10
520
525
35
100
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ± 0.25(0.01") unless otherwise noted.
3.Specifications are subject to change without notice.
Features
OUTSTANDING MATERIAL EFFICIENCY.
RELIABLE AND RUGGED.
WATER CLEAR LENS.
LOW POWER CONSUMPTION.
ONE BLUE, ONE RED AND ONE GREEN CHIPS
IN ONE PACKAGE.
CAN PRODUCE ANY COLOR IN VISIBLE SPEC-
TRUM,INCLUDING WHITE LIGHT.
MOISTURE SENSITIVITY LEVEL : LEVEL 4
●RoHS COMPLIANT.
PRELIMINARY SPEC
Absolute Maximum Ratings
(TA=25°C)
BBG
(InGa
N)
MD
(InGaA
lP)
BGA
(InGa
N)
Unit
Reverse Voltage
VR
5
V
Forward Current
IF
30
50
30
mA
Forward Current (peak)
1/10Duty Cycle
0.1ms Pulse Width
iFS
100
185
100
mA
Total Power Dissipation
Within 350mW At All
Chips Are Lightened
PT
mW
Electrostatic Discharge
Threshold (HBM)
1000
-
1000
V
Operating Temperature
TA
-40 ~ +85
°C
Storage Temperature
Tstg
-40 ~ +85
Lead Solder Temperature
[2mm Below Package Base]
260°C For 3 Seconds
Lead Solder Temperature
[5mm Below Package Base]
260°C For 5 Seconds
350
