| 型號： | SD1146 |
| 廠商： | MICROSEMI POWER PRODUCTS GROUP |
| 元件分類： | 功率晶體管 |
| 英文描述： | RF & MICROWAVE TRANSISTORS |
| 中文描述： | UHF BAND, Si, NPN, RF POWER TRANSISTOR |
| 封裝： | 0.280 INCH, PLASTIC, M122, 4 PIN |
| 文件頁數： | 1/4頁 |
| 文件大小： | 175K |
| 代理商： | SD1146 |
Microsemi
RF Products Division
140 Commerce Drive, Montgomeryville PA 18936, (215) 631-9840, Fax: (215) 631-9855
Page 1
Copyright
2000
MSC1613.PDF 2000-11-26
W
M
.
C
SD1146
RF & MICROWAVE TRANSISTORS
P
RODUCT
P
REVIEW
RF PRODUCTS DIVISION
DESCRIPTION
The SD1146 is a 12.5 V Class C epitaxial silicon NPN planar
transistor designed primarily for UHF communications. This device
utilizes improved metallization to achieve infinite VSWR at rated
operating conditions
.
IMPORTANT:
For the most current data, consult
MICROSEMI
’s website:
http://www.microsemi.com
KEY FEATURES
!"
470 MHz
!"
12.5 Volts
!"
Efficiency 60%
!"
Common Emitter
!"
P
OUT
= 10 W Min.
!"
G
P
= 6.0 dB Gain
APPLICATIONS/BENEFITS
!"
UHF Mobile
Applications
ABSOLUTE MAXIMUM RATINGS
(T
CASE
= 25
°
C)
Parameter
Collector-Base Voltage
Collector-Emitter Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Device Current
Power Dissipation
Junction Temperature
Storage Temperature
Symbol
V
CBO
V
CEO
V
CES
V
EBO
I
C
P
DISS
T
J
T
STG
Value
36
16
36
4.0
2.0
37.5
+200
-65 to +150
Unit
V
V
V
V
A
W
°
C
°
C
THERMAL DATA
R
TH(j-c)
Junction-Case Thermal Resistance
4.7
°
C/W
S
D
1
1
4
6
