221 West Industry Court Deer Park, NY 11729-4681 (631) 586-7600 FAX (631) 242-9798
World Wide Web Site - http://www.sensitron.com
E-Mail Address - sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 520, REV. B
SILICON SCHOTTKY RECTIFIER DIE
Very Low Forward Voltage Drop
200
°
C Operating Temperature
Applications:
Switching Power Supply
Converters
Free-Wheeling Diodes
Polarity Protection Diode
Features:
Soft Reverse Recovery at Low and High Temperature
Very Low Forward Voltage Drop
Low Power Loss, High Efficiency
High Surge Capacity
Guard Ring for Enhanced Durability and Long Term Reliability
Guaranteed Reverse Avalanche Characteristics
Electrically / Mechanically Stable during and after Packaging
Out Performs 100 Volt Ultrafast Rectifiers
Maximum Ratings:
Characteristics
Symbol
Peak Inverse Voltage
V
RWM
Max. Average Forward
Current
wave form
Max. Peak One Cycle Non-
Repetitive Surge Current
Non-Repetitive Avalanche
Energy
L = 56 mH
Repetitive Avalanche Current
I
AR
I
AS
decay linearly to 0 in 1
μ
s
limited by T
J
max V
A
=1.5V
R
Max. Junction Temperature
T
J
Max. Storage Temperature
T
stg
Electrical Characteristics:
Characteristics
Symbol
Max. Forward Voltage Drop
V
F1
@ 15A, Pulse, T
J
= 25
°
C
V
F2
@ 15A, Pulse, T
J
= 125
°
C
Max. Reverse Current
I
R1
@V
R
= 100V, Pulse,
T
J
= 25
°
C
I
R2
@V
R
= 100V, Pulse,
T
J
= 125
°
C
Max. Junction Capacitance
C
T
@V
R
= 5V, T
C
= 25
°
C
f
SIG
= 1MHz,
V
SIG
= 50mV (p-p)
(1) in SHD package
Condition
-
Max.
100
15
Units
V
A
I
F(AV)
50% duty cycle, rectangular
I
FSM
8.3 ms, half Sine wave
(1)
280
A
E
AS
T
J
= 25
°
C, I
AS
= 0.53 A,
8.0
mJ
0.53
A
-
-
-65 to +200
-65 to +200
°
C
°
C
Condition
Max.
0.84
0.68
350
Units
V
V
μ
A
8
mA
500
pF
SD125SC100A/B/C
