SED1560 Series
1
G
Ultra Low Power Consumption
G
Built-in Power Supply Circuit for LCD
G
167 Driver Output
Dot Matrix LCD Controller Driver
I
DESCRIPTION
The SED1560 series is a single-chip LCD driver for dot-matrix liquid crystal displays. It accepts serial or 8-bit
parallel display data directly from a microprocessor and stores data in an on-chip 166
×
65-bit RAM.
The SED1560 features 167 common and segment outputs to drive either a 65
×
102-pixel display (4 rows
×
6
columns with 16
×
16-pixel characters) or a 33
×
134-pixel display (2 rows
×
8 columns with 16
×
16-pixel
characters) or a 17
×
150-pixel display (1 row
×
9 columns with 16
×
16 characters). In addition, two SED1560s
can be connected together to drive a 65
×
268-pixel graphics display panel.
The SED 1560 series can read and write RAM data with the minimum current consumption as it does not require
any external operation clock. Also, it has a built-in LCD power supply featuring the very low current consumption
and, therefore, the display system of a high-performance but handy instrument can be realized by use of the
minimum current consumption and LSI chip configuration.
The SED 1560 Series has the SED1560, SED1561 and SED1562 available according to the duty.
I
FEATURES
G
On-chip 166
×
65-bit display RAM
G
Direct relationship between RAM bits and display pixels.
G
High speed Interfaces to 6800- and 8080-series microprocessors
G
Selectable 8-bit parallel/serial interface
G
Many command functions
G
On-chip DC/DC voltage converter, voltage regulator and voltage followers for LCD driver voltage generation.
G
Type 1 (SED156
*
D
0
*
, SED156
D
A
) ................... 0.2%/
°
C
G
Type 2 (SED156
D
E
) ............................................ 0.00%/
°
C
G
On Chip Contrast control.
G
On-chip oscillator
G
Ultra low power consumption
G
Power Supply
V
DD
– V
SS
–2.4 V to 6.0 V
V
DD
– V
5
–3.5 V to 16.0 V (In the case of extarnal power supply)
G
Ta = –30 to 85
°
C
G
CMOS process
G
TCP, QTCP
G
The system is not designed against the radio activity.
I
LINE UP
Wide variety of duty and display areas
Model
Duty
1/65
1/64
1/49
1/48
1/33
1/32
1/25
1/24
1/17
1/16
LCD bias
Single-chip display area
65
×
102
64
×
102
49
×
102
48
×
102
33
×
134
32
×
134
25
×
134
24
×
134
17
×
150
16
×
150
SED1560
1/9
1/7
SED1561
1/7
1/5
SED1562
1/5
Note: The LCD bias is obtained if the built-in power supply is used.
PF670-04
SED1560
Series
