SED1570D
0A
1
G
80 Output Segment Driver
G
Built-in Display RAM 80
×
200 bits
G
Self-refresh Function
Dot Matrix High Duty LCD Driver
PF783-02
SED1570D
I
DESCRIPTION
The SED1570 is an 80 output segment (column) driver with an internal display RAM. This drive is suitable for
driving a dot matrix LCD panel; from a mid-range capacity dot matrix LCD panel to a CGA class dot matrix LCD
panel. This device is used with the SED1635.
The display data is stored in the internal display RAM and an LCD panel drive signal is generated. As a result,
this device allows configuration of an ultra low power display system since the display data is not transferred unless
the display is changed.
In addition, the logic power is low voltage; a wide range of applications is possible.
I
FEATURES
G
Display duty cycle: 1/64 – 1/200
G
LCD driver output: 80 out
G
Internal display RAM: 200
×
80 bits
G
Slim chip
G
Ultra low power consumption
G
Power
V
DD
– V
SS
V
DD
– V
EE
G
High speed and low power date transfer by the 4-bit bus enables chain method
G
Non-bias display off function
G
Output shift direction-pin selection
G
Adjustable LCD power offset bias for V
DD
level
G
Package: Die form SED1570D
0A
(Al pad)
SED1570D
0B
(Au bump)
2.7 V to 5.5 V
8.0 V to 20 V
I
PAD DIMENSIONS
Chip Size
Pad Center Size
Pad Pitch
Chip Thickness
8.04 mm
×
3.51 mm
100
μ
m
×
100
μ
m
170
μ
m (Min.)
400
μ
m
±
25
μ
m (Al Pad)
Bump Size
Pump Pitch
Chip Thickness
Bump Height
92
μ
m
×
82
μ
m
170
μ
m (Min.)
525
μ
m
17 to 28
μ
m (reference)
31
1
50
81
32
49
99
82
Y
X
D1570D
