參數資料
| 型號： | SFAF1608G |
| 元件分類： | 整流器 |
| 英文描述： | 16 A, 600 V, SILICON, RECTIFIER DIODE, TO-220AC |
| 封裝： | PLASTIC PACKAGE-2 |
| 文件頁數： | 1/3頁 |
| 文件大小： | 264K |
| 代理商： | SFAF1608G |
Voltage
200 to 600 V
Current
16 A
Jul - 07
VF
Max. forward voltage drop
at IF = 16 A
IR
Max. Instantaneous reverse
current at VR = VRRMax
Rthj-C
Typical Thermal Resistance
1.3 °C/W
Tj = 100 C
1.3 V
Tj = 25 C
Tj = 25 °C
Peak recurrent reverse voltage (V)
Maximum RMS voltage (V)
Maximum DC blocking voltage (V)
Maximum average Forward current.
at TC = 100 °C
VRRM
VRMS
VDC
IF (AV)
Tj
Tstg
Operating temperature range
Storage temperature range
– 65 to + 150 °C
IFSM
8.3 ms. peak forward surge current
(Jedec Method)
16 A
200 A
– 65 to + 150 °C
200
600
140
420
200
600
Cj
Typical Junction Capacitance at 1 MHz
and reverse voltaje of 4VDC
100 pF
10 A
400 A
Glass Passivated Junction
High current capability
The plastic material carries
U/L recognition 94 V-0
Terminals: Leads solderable per
MIL-STD202
Low forward Voltage drop
SFAF1604G
SFAF1608G
SFAF16G
Absolute Maximum Ratings, according to IEC publication No. 134
Electrical Characteristics
16 Amp. Glass Passivated Ultrafast Recovery Rectifier
Max. reverse recovery time from
IF = 0.5 A ; IR = 1 A ; IRR = 0.25 A
SFAF1606G
400
280
400
SFAF1604G
SFAF1608G
SFAF1606G
35 ns
TRR
ITO-220AC
130 pF
0.975 V
1.7 V
1
2
1
Case Positive
2
Case
