USA/Canada 1-800-278-5666
Asia +886-3-5821124
USA/Canada 1-847-359-8904
Asia +886-3-5821154
www.lumex.com
158
SMT LEDs ~ Transfer Molded ~ Package Style 1206
SML-LXR1206XC-TR
Flat Solder Terminals
Reverse Mount
SML-LXR1206XC Package Style - Super Bright
Flat Solder Terminals
Reverse Mount
SML-LXR1206XC Package Style - Ultra Bright
Flat Solder Terminals
Reverse Mount
Standard 1206 Package
State-of-the-Art LED Die
Wide Angle of Emission
High Volume Capacity Production
Quick Delivery
All Color Choices Available
Features/Options
Applications/Uses
Display or Character Backlighting
Status Indicators
Circuit Fault Indicators
Keyboard Post Lighting
Medical Diagnostic Instruments
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Axial
Intensity
@
If=20mA
V
f Typ
@
If=20mA
V
f Max
@
If=20mA
View
Angle° 2θ
Reel
Size
(pcs)
Reflow
Profile
Pg. 134
Tape
Specs
Pg. 134
SML-LXR1206SIC-TR
AllnGaP
Super High Intensity Red
636
Clear
180
2.0
2.2
120
2000
Figure 1
Figure A
SML-LXR1206SOC-TR
AllnGaP
Super Orange
610
Clear
250
2.0
2.5
120
2000
Figure 1
Figure A
SML-LXR1206SRC-TR
GaAIAs
Super Red
660
Clear
70
1.7
2.2
120
2000
Figure 1
Figure A
SML-LXR1206SUGC-TR AllnGaP
Super Ultra Green
574
Clear
45
2.2
2.6
120
2000
Figure 1
Figure A
SML-LXR1206SYC-TR
AllnGaP
Super Yellow
590
Clear
70
2.0
2.5
120
2000
Figure 1
Figure A
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Axial
Intensity
@
If=20mA
V
f Typ
@
If=20mA
V
f Max
@
If=20mA
View Angle°
2θ
Reel
Size
(pcs)
Reflow
Profile
Pg. 134
Tape
Specs
Pg. 134
SML-LXR1206USBC-TR
InGaN
Ultra Super Blue
470
Clear
45
3.5
4.0
120
2000
Figure 1
Figure A
SML-LXR1206UPGC-TR
InGaN
Ultra Pure Green
525
Clear
25
3.5
4.0
120
2000
Figure 1
Figure A
1
29
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
