參數資料
| 型號： | SN74LS04N |
| 廠商： | MOTOROLA INC |
| 元件分類： | 通用總線功能 |
| 英文描述： | HEX INVERTER LOW POWER SCHOTTKY |
| 中文描述： | LS SERIES, HEX 1-INPUT INVERT GATE, PDIP14 |
| 封裝： | 646-06 |
| 文件頁數： | 1/2頁 |
| 文件大?。?/td> | 46K |
| 代理商： | SN74LS04N |
5-10
FAST AND LS TTL DATA
HEX INVERTER
14
13
12
11
10
9
1
2
3
4
5
6
VCC
8
7
GND
GUARANTEED OPERATING RANGES
Symbol
Parameter
Min
Typ
Max
Unit
VCC
Supply Voltage
54
74
4.5
4.75
5.0
5.0
5.5
5.25
V
TA
Operating Ambient Temperature Range
54
74
–55
0
25
25
125
70
°
C
IOH
IOL
Output Current — High
54, 74
–0.4
mA
Output Current — Low
54
74
4.0
8.0
mA
SN54/74LS04
HEX INVERTER
LOW POWER SCHOTTKY
J SUFFIX
CERAMIC
CASE 632-08
N SUFFIX
PLASTIC
CASE 646-06
14
1
14
1
ORDERING INFORMATION
SN54LSXXJ
SN74LSXXN
SN74LSXXD
Ceramic
Plastic
SOIC
14
1
D SUFFIX
SOIC
CASE 751A-02
