USA/Canada 1-800-278-5666
Asia +886-3-5821124
USA/Canada 1-847-359-8904
Asia +886-3-5821154
www.lumex.com
127
Arrays ~ Chips-On-Board
FEATURES / OPTIONS
State-of-the-Art, High Brightness Chip Technology
Pre-Sorted Chips Prior to Bonding on PCB
Easy Installation Over Using Individual LEDs
Choice of Colors and Color Combinations
White Reflector to Maximize Light Output
CustomArrays, Easily Developed, Low Minimum
Black or Gray Face for High Contrast
SSA-LXB4355 Series
2.8x5.35mm Rectangular COB Array, 4 Chips
SSA-LXB10 Series
1.78x5mm Rectangular COB Array, 10 Chips
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Operating
Current (mA)
Operating
TYP. Vf (V)
Brightness
TYP. Mcd
@
mA
View Angle°
2θ
HIGH BRIGHTNESS
SSA-LXB10SIW
AlInGaP
Super High Intensity Red
636
Milky White Diffused
5-25
2
80
20
160
SSA-LXB10SOW
AlInGaP
Super Orange
610
Milky White Diffused
5-25
2
80
20
160
SSA-LXB10SUGW
AlInGaP
Super Ultra Green
574
Milky White Diffused
5-25
2.2
40
20
160
SSA-LXB10SYW
AlInGaP
Super Yellow
590
Milky White Diffused
5-25
2
80
20
160
SSA-LXB10USBW
InGaN/SiC
Ultra Super Blue
470
Milky White Diffused
5-25
3.5
50
20
160
STANDARD BRIGHTNESS
SSA-LXB10GW
GaP
Green
565
Milky White Diffused
5-25
2.2
12
20
160
SSA-LXB10IW
GaAsP
High Intensity Red
635
Milky White Diffused
5-25
2.0
12
20
160
SSA-LXB10SRW
GaAlAs
Super Red
660
Milky White Diffused
5-25
1.8
50
20
160
SSA-LXB10YW
GaAsP
Yellow
585
Milky White Diffused
5-25
2.1
12
20
160
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Operating
Current (mA)
Operating
TYP. Vf (V)
Brightness
TYP. Mcd
@ mA
View Angle°
2θ
HIGH BRIGHTNESS
SSA-LXB4355SIW
AlInGaP
Super High Intensity Red
636
Milky White Diffused
5-25
2
80
20
160
SSA-LXB4355SOW
AlInGaP
Super Orange
610
Milky White Diffused
5-25
2
80
20
160
SSA-LXB4355SUGW
AlInGaP
Super Ultra Green
574
Milky White Diffused
5-25
2.2
40
20
160
SSA-LXB4355SYW
AlInGaP
Super Yellow
590
Milky White Diffused
5-25
2
80
20
160
SSA-LXB4355USBW
InGaN/SiC
Ultra Super Blue
470
Milky White Diffused
5-25
3.5
50
20
160
FEATURES / OPTIONS
State-of-the-Art, High Intensity Chip Technology
Pre-Sorted Chips for Color & Industry Uniformity
Easy Installation Over Using Individual LEDs
Choice of Colors and Color Combinations
CustomArrays, Easily Developed, Low Minimum
APPLICATIONS / USES
Level, VU, Power Indicators
Ladder or RangeAnnunicator
ProfessionalAudio Equipment
Power Stations, Power Level Indicator
Medical Diagnostics, Test Equipment
Industrial Control Panels
APPLICATIONS / USES
Level, VU, Power Indicators
Ladder or RangeAnnunicator
ProfessionalAudio Equipment
Power Stations, Power Level Indicator
Medical Diagnostics, Test Equipment
Industrial Control Panels
1
29
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
