USA/Canada 1-800-278-5666
Asia +886-3-5821124
USA/Canada 1-847-359-8904
Asia +886-3-5821154
www.lumex.com
123
Arrays ~ Multi-Chip Light Bars
SSB-LX620xx Series
6x20mm, 3-Chip Light Bars
SSB-LX500 SERIES
7x14mm (2) Chip Light Bar
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Operating
Current (mA)
Operating
TYP. Vf (V)
Brightness
TYP. Mcd
@
mA
View Angle°
2θ
SSB-LX620SID
AlInGaP
Super High Intensity Red
636
Red Diffused
2.0
2.6
80
20
160
SSB-LX620SIW
AlInGaP
Super High Intensity Red
636
White Diffused
2.0
2.6
80
20
160
SSB-LX620SOD
AlInGaP
Super Orange
610
Orange Diffused
2.0
2.6
75
20
160
SSB-LX620SOW
AlInGaP
Super Orange
610
White Diffused
2.0
2.6
75
20
160
SSB-LX620SUGD
AlInGaP
Super Ultra Green
574
Green Diffused
2.2
2.6
65
20
160
SSB-LX620SUGW
AlInGaP
Super Ultra Green
574
White Diffused
2.2
2.6
65
20
160
SSB-LX620SYD
AlInGaP
Super Yellow
590
Yellow Diffused
2.0
2.6
80
20
160
SSB-LX620SYW
AlInGaP
Super Yellow
590
White Diffused
2.0
2.6
80
20
160
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Operating
Current (mA)
Operating
TYP. Vf (V)
Brightness
TYP. Mcd
@
mA
View Angle° 2θ
SSB-LX500SID
AlInGaP
Super High Intensity Red
636
Red Diffused
2.0
2.6
80
20
160
SSB-LX500SIW
AlInGaP
Super High Intensity Red
636
White Diffused
2.0
2.6
80
20
160
SSB-LX500SOD
AlInGaP
Super Orange
610
Orange Diffused
2.0
2.6
75
20
160
SSB-LX500SOW
AlInGaP
Super Orange
610
White Diffused
2.0
2.6
75
20
160
SSB-LX500SUGD
AlInGaP
Super Ultra Green
574
Green Diffused
2.2
2.6
60
20
160
SSB-LX500SUGW
AlInGaP
Super Ultra Green
574
White Diffused
2.2
2.6
60
20
160
SSB-LX500SYD
AlInGaP
Super Yellow
590
Yellow Diffused
2.0
2.6
80
20
160
SSB-LX500SYW
AlInGaP
Super Yellow
590
White Diffused
2.0
2.6
80
20
160
FEATURES / OPTIONS
State-of-the-Art, High Intensity Chip Technology
Pre-Sorted Chips for Color & Industry Uniformity
High Light Reflectivity & Low Cross-Talk Reflectors
Advanced Chip on Board Technology
Choice of Colors and Color Combinations
Custom Designs, Easily Developed, Low Minimum
APPLICATIONS / USES
Backlighting Legends or Switches
Large PCB Installed Indicators
Keyboard Status Indicators
Medical Diagnostics Equipment
IndustrialAutomation Controls
Control Panel Indicators
FEATURES / OPTIONS
State-of-the-Art, High Intensity Chip Technology
Pre-Sorted Chips for Color & Industry Uniformity
High Light Reflectivity & Low Cross-Talk Reflectors
Advanced Chip on Board Technology
Choice of Colors and Color Combinations
Custom Designs, Easily Developed, Low Minimum
APPLICATIONS / USES
Backlighting Legends or Switches
Large PCB Installed Indicators
Keyboard Status Indicators
Medical Diagnostics Equipment
IndustrialAutomation Controls
Control Panel Indicators
