| 型號： | SSL-LXA228SUGC-TR31 |
| 廠商： | LUMEX INC |
| 元件分類： | LED |
| 英文描述： | T-3/4 SINGLE COLOR LED, ULTRA SUPER GREEN, 1.9 mm |
| 封裝： | PLASTIC, SMT, 2 PIN |
| 文件頁數： | 1/1頁 |
| 文件大小： | 246K |
| 代理商： | SSL-LXA228SUGC-TR31 |
USA/Canada 1-800-278-5666
Asia +886-3-5821124
USA/Canada 1-847-359-8904
Asia +886-3-5821154
www.lumex.com
167
SMT LEDs ~ Transfer Molded ~ Axial Leaded
SSL-LXA228XC-TR31
Transfer Molded
Z-Bend Axial Leads
SSL-LXA228 Package Style - Super Bright
Transfer Molded
Z-Bend Axial Leads
SSL-LXA228 Package Style - Ultra Bright
Transfer Molded
Z-Bend Axial Leads
Applications/Uses
Keyboard/Keypad Illumination
Circuit Fault Indicators
Position Indicators
Display or Character Backlighting
Control Board Indicators
Medical Diagnostic Instruments
Epoxy Lead Frame
Molded Axial Package
Lead Frame Soldering Reliability
State-of-the-Art LED Die
Built-In Round or Flat Lenses
Trimmed and Formed Leads
Features/Options
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Axial
Intensity
@
If=20mA
V
f Typ
@
If=20mA
V
f Max
@
If=20mA
View Angle°
2θ
Reel
Size
(pcs)
Reflow
Profile
Pg. 134
Tape
Specs
Pg. 134
SSL-LXA228SIC-TR31
AllnGaP
Super High Intensity Red
636
Clear
475
2.0
2.6
25
1000 Figure 1 Figure B
SSL-LXA228SOC-TR31
AllnGaP
Super Orange
610
Clear
700
2.0
2.5
25
1000 Figure 1 Figure B
SSL-LXA228SRC-TR31
GaAIAs
Super Red
660
Clear
600
1.7
2.2
25
1000 Figure 1 Figure B
SSL-LXA228SUGC-TR31
AllnGaP
Super Ultra Green
574
Clear
200
2.2
2.6
25
1000 Figure 1 Figure B
SSL-LXA228SYC-TR31
AllnGaP
Super Yellow
590
Clear
250
2.0
2.5
25
1000 Figure 1 Figure B
Lumex Part Number
Die Material
Emitted Color
Peak
(nm)
Lens
Axial
Intensity
@
If=20mA
V
f Typ
@
If=20mA
V
f Max
@
If=20mA
View Angle°
2θ
Reel
Size
(pcs)
Reflow
Profile
Pg. 134
Tape
Specs
Pg. 134
SSL-LXA228USBCTR31
InGaN
Ultra Super Blue
470
Clear
250
3.5
4.0
25
1000
Figure 1
Figure B
SSL-LXA228UPGCTR31
InGaN
Ultra Pure Green
525
Clear
1400
3.5
4.0
25
1000
Figure 1
Figure B
