TFP201, TFP201A
TI PanelBus
DIGITAL RECEIVER
SLDS116 - MARCH 2000
17
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
Table 1 outlines the thermal properties of the TI 100-TQFP PowerPAD package. The 100-TQFP non-PowerPAD
package is included only for reference.
Table 1. TI 100-TQPF (14
× 14 × 1.4 mm)/0.5 mm Lead Pitch
PARAMETER
WITHOUT
PowerPAD
NOT CONNECTED TO PCB
THERMAL PLANE
PowerPAD
CONNECTED TO PCB
THERMAL PLANE
Theta-JA,
45
°C/W
27.3
°C/W
17.3
°C/W
Theta-JC,
3.11
°C/W
0.12
°C/W
0.12
°C/W
Maximum power dissipation,,§
1.6 W
2.7 W
4.3 W
Maximum TFP201/201A pixel rate
TBD
Specified with 2 oz. Cu PCB plating.
Airflow is at 0 LFM (no airflow)
§ Measured at ambient temperature, TA = 70°C.
ADV
ANCE
INFORMA
TION
