THS1206EP
12BIT 6 MSPS, SIMULTANEOUS SAMPLING
ANALOGTODIGITAL CONVERTERS
SGLS126A JULY 2002 REVISED FEBRUARY 2003
5
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
electrical characteristics over recommended operating conditions, VREF = internal (unless
otherwise noted)
digital specifications
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Digital inputs
IIH
High-level input current
DVDD = digital inputs
50
A
IIL
Low-level input current
Digital input = 0 V
50
A
Ci
Input capacitance
5
pF
Digital outputs
VOH
High-level output voltage
BVDD0.5
V
VOH
High-level output voltage
IOH = 50 A
BVDD = 3.3 V,
BVDD0.5
V
VOL
Low-level output voltage
IOH = 50 A
BVDD = 3.3 V,
BVDD = 5 V
0.4
V
VOL
Low-level output voltage
BVDD = 5 V
0.4
V
IOZ
High-impedance-state output current
CS1 = DGND,
CS0 = DVDD
10
A
CO
Output capacitance
5
pF
CL
Load capacitance at databus D0 D11
30
pF
dc specifications
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Resolution
12
Bits
Accuracy
Integral nonlinearity, INL
±1.8
LSB
Differential nonlinearity, DNL
±1
LSB
Offset error
After calibration in single-ended mode
20
LSB
Offset error
After calibration in differential mode
20
LSB
Gain error
20
LSB
Analog input
Input capacitance
15
pF
Input leakage current
VAIN = VREFM to VREFP
±10
A
Internal voltage reference
Accuracy, VREFP
3.3
3.5
3.7
V
Accuracy, VREFM
1.3
1.5
1.7
V
Temperature coefficient
50
PPM/
°C
Reference noise
100
V
Accuracy, REFOUT
2.3
2.5
2.7
V
Power supply
IDDA
Analog supply current
AVDD = 5 V, BVDD = DVDD = 3.3 V
36
40
mA
IDDD
Digital supply voltage
AVDD = 5 V, BVDD = DVDD = 3.3 V
0.5
1
mA
IDDB
Buffer supply voltage
AVDD = 5 V, BVDD = DVDD = 3.3 V
1.5
4
mA
IDD_P
Supply current in power-down mode
AVDD = 5 V, BVDD = DVDD = 3.3 V
10
mA
Power dissipation
AVDD = 5 V, DVDD = BVDD = 3.3 V
186
216
mW
Power dissipation in power down
AVDD = 5 V, DVDD = BVDD = 3.3 V
30
mW
Not production tested.
