參數資料
型號： THS4225DRG4
廠商： TEXAS INSTRUMENTS INC
元件分類： 音頻／視頻放大
英文描述： 1 CHANNEL, VIDEO PREAMPLIFIER, PDSO8
封裝： GREEN, PLASTIC, SOIC-8
文件頁數： 23/38頁
文件大小： 1428K
代理商： THS4225DRG4
THS4221, THS4225
THS4222, THS4226
SLOS399G AUGUST 2002 REVISED JANUARY 2004
www.ti.com
3
THS4222 AND THS4226 DUAL PACKAGE/ORDERING INFORMATION
PACKAGED DEVICES
PLASTIC SMALL OUTLINE
PLASTIC MSOP PowerPADE(1)
PLASTIC MSOPE(1)
PLASTIC SMALL OUTLINE
(D)(1)
(DGN)
SYM
(DGQ)
SYM
(DGK)
SYM
THS4222D
THS4222DGN
BFO
—
THS4222DGK
BHW
—
THS4226DGQ
BFP
—
(1) All packages are available taped and reeled. The R suffix standard quantity is 2500 (e.g., THS4222DGNR).
ELECTRICAL CHARACTERISTICS
VS = ±5 V, RL = 499 , and G = 1 unless otherwise noted
TYP
OVER TEMPERATURE
PARAMETER
TEST CONDITIONS
25°C
0°C to
70°C
40°C to
85°C
UNITS
MIN/
MAX
AC PERFORMANCE
G = 1, PIN = 7 dBm
230
MHz
Typ
Small signal bandwidth
G = 2, PIN = 13 dBm, Rf = 1.3 k
100
MHz
Typ
Small signal bandwidth
G = 5, PIN = 21 dBm, Rf = 2 k
25
MHz
Typ
G = 10, PIN = 27 dBm, Rf = 2 k
12
MHz
Typ
0.1 dB flat bandwidth
G = 2, PIN = 13 dBm, Rf = 1.3 k
40
MHz
Typ
Gain bandwidth product
G > 10, f = 1 MHz, Rf = 2 k
120
MHz
Typ
Full-power bandwidth
G = 1, VO = ±2.5 V
65
MHz
Typ
Slew rate
G = 1, VO = ±2.5 Vpp
990
V/s
Min
Slew rate
G = 1, VO = ±2.5 Vpp
975
V/s
Min
Settling time to 0.1%
G = 1, VO = ±2 Vpp
25
ns
Typ
Settling time to 0.01%
G = 1, VO = ±2 Vpp
52
ns
Typ
Harmonic distortion
G = 1, VO = 2 VPP, f = 5 MHz
Second harmonic distortion
RL = 499
90
dBc
Typ
Second harmonic distortion
RL = 150
92
dBc
Typ
Third harmonic distortion
RL = 499
100
dBc
Typ
Third harmonic distortion
RL = 150
96
dBc
Typ
Differential gain (NTSC, PAL)
G = 2, R = 150
0.007
%
Typ
Differential phase (NTSC, PAL)
G = 2, R = 150
0.007
°
Typ
Input voltage noise
f = 1 MHz
13
nV/√Hz
Typ
Input current noise
f = 1 MHz
0.8
pA/√Hz
Typ
Crosstalk (dual only)
f = 5 MHz Ch-to-Ch
90
dB
Typ
DC PERFORMANCE
Open-loop voltage gain (AOL)
VO = ±2 V
100
80
75
dB
Min
Input offset voltage
VCM = 0 V
3
10
16
mV
Max
Average offset voltage drift
VCM = 0 V
±20
V/_C
Typ
Input bias current
VCM = 0 V
0.9
3
5
A
Max
Average offset voltage drift
VCM = 0 V
±10
V/_C
Typ
Input offset current
VCM = 0 V
100
500
700
nA
Max
Average offset current drift
VCM = 0 V
±10
nA/_C
Typ
INPUT CHARACTERISTICS
Common-mode input range
4 / 4
3.9 / 3.9
V
Min
Common-mode rejection ratio
VCM = ±2 V
94
74
69
dB
Min
Input resistance
33
M
Typ
Input capacitance
Common-mode / differential
1 / 0.5
pF
Max
