TLC7528C, TLC7528E, TLC7528I
DUAL 8-BIT MULTIPLYING
DIGITAL-TO-ANALOG CONVERTERS
SLAS062C – JANUARY 1987 – REVISED SEPTEMBER 2000
8
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
APPLICATION INFORMATION
+
–
R11
5 k
A2
VOA
DACB
R6
20 k
(see Note B)
VOB
+
–
AGND
A1
DGND
A4
R3
(see Note A)
R1
(see Note A)
AGND
+
–
C1
(see Note C)
C2
(see Note C)
R2 (see Note A)
R4 (see Note A)
+
–
AGND
OUTB
RFBB
AGND
OUTA
5
VDD
17
7
14
DACA/
DACB
DB0
DB7
8
REFB
RFBA
DACA
CS
WR
16
15
6
A3
R10
20 k
(see Note B)
Latch
Input
Buffer
Control
Logic
Latch
R8
20 k
R7
10 k
(see Note B)
R9
10 k
(see Note B)
R11
5 k
R5
20 k
VI(A)
±10 V
VI(B)
±10 V
NOTES: A. R1, R2, R3, and R4 are used only if gain adjustment is required. See table in Figure 3 for recommended values. Adjust R1 for
VOA = 0 V with code 10000000 in DACA latch. Adjust R3 for VOB = 0 V with 10000000 in DACB latch.
B. Matching and tracking are essential for resistor pairs R6, R7, R9, and R10.
C. C1 and C2 phase compensation capacitors (10 pF to 15 pF) may be required if A1 and A3 are high-speed amplifiers.
Figure 4. Bipolar Operation (4-Quadrant Operation)
Table 1. Unipolar Binary Code
Table 2. Bipolar (Offset Binary) Code
DAC LATCH CONTENTS
ANALOG OUTPUT
DAC LATCH CONTENTS
ANALOG OUTPUT
MSB
LSB
ANALOG OUTPUT
MSB
LSB
ANALOG OUTPUT
1 1 1 1 1 1 1 1
1 0 0 0 0 0 0 1
1 0 0 0 0 0 0 0
0 1 1 1 1 1 1 1
0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0
–VI (255/256)
–VI (129/256)
–VI (128/256) = – Vi/2
–VI (127/256)
–VI (1/256)
–VI (0/256) = 0
1 1 1 1 1 1 1 1
1 0 0 0 0 0 0 1
1 0 0 0 0 0 0 0
0 1 1 1 1 1 1 1
0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0
VI (127/128)
VI (1/128)
0 V
–VI (1/128)
–VI (127/128)
–VI (128/128)
1 LSB = (2–8)VI
1 LSB = (2–7)VI
