TLE 6361 G
Data Sheet, Rev. 2.0
4
2005-03-01
1.4
Pin definitions and functions
Pin No.
Symbol
Function
1,18,19,
36
GND
Ground; to reduce thermal resistance place cooling areas on
PCB close to this pins. Those pins are connected internally to the
heatslug at the bottom.
2
CLK
SPI Interface Clock input; clocks the shiftregister; CLK has an
internal active pull down and requires CMOS logic level
inputs;see also chapter SPI
3
CS
SPI Interface chip select input; CS is an active low input; serial
communication is enabled by pulling the CS terminal low; CS
input should only be switched when CLK is low; CS has an
internal active pull up and requires CMOS logic level inputs ;see
also chapter SPI
4
DI
SPI Interface Date input; receives serial data from the control
device; serial data transmitted to DI is a 16 bit control word with
the Least Significant Bit (LSB) being transferred first; the input
has an active pull down and requires CMOS logic level inputs; DI
will accept data on the falling edge of CLK-signal; see also
chapter SPI
5
DO
SPI Interface Data output; this tristate output transfers
diagnosis data to the controlling device; the output will remain 3-
stated unless the device is selected by a low on Chip-Select CS;
see also the chapter SPI
6
ERR
Error output; push-pull output. Monitors failures in parallel to the
SPI diagnosis word, reset via SPI. ERR is a latched output.
7
Q_STB
Standby Regulator Output; the output is active even when the
buck regulator and all other circuitry is in off mode
8
Q_T1
Voltage Tracker Output T1 tracked to Q_LDO1; bypass with a
1F ceramic capacitor for stability. It is switched on and off by
SPI command. Keep open, if not needed.
9
Q_T2
Voltage Tracker Output T2 tracked to Q_LDO1; bypass with a
1F ceramic capacitor for stability. It is switched on and off by
SPI command. Keep open, if not needed.
10
Q_T3
Voltage Tracker Output T3 tracked to Q_LDO1; bypass with a
1F ceramic capacitor for stability. It is switched on and off by
SPI command. Keep open, if not needed.
