TLE 6389
Preliminary data sheet Rev. 1.0
4
2003-05-05
1.5
Pin Definitions and Functions
Pin No
SO-14
Symbol
Function
1
ENABLE Active-High enable input (only at adjustable version, TLE6389GV) for
the device.
The device is shut down when ENABLE is driven low. In this shut down-
mode the reference, the output and the external MOSFET are turned off.
Connect to logic high for normal operation.
1SI_ENA
BLE
Active-High enable input (only at 5V version, TLE6389G50-1 and
TLE6389G50) for SI_GND input.
SI_GND is switched to high impedance when SI_ENABLE is low. High
level at SI_ENABLE connects SI_GND to GND with low impedance. SO is
undefined when SI_ENABLE is low.
2FB
Feedback input.
1. For adjustable version (GV) connect this pin to an external voltage
divider from the output to GND (see the determining the output voltage,
application section).
2. At the 5V fixed output voltage version (G50-1 and G50) the FB is
connected internally to an on-chip voltage divider. It does not have to be
connected externally to the output.
3VOUT
Buck output voltage input.
Input for the internal supply. Connect to the output capacitance of the buck
converter.
4GND
Ground connection. Analog signal ground.
5SYNC
Input for external frequency synchronization.
An external clock signal connected to this pin allows switching frequency
synchronization of the device. The internal oscillator is clocked then by the
frequency applied at the SYNC input.
6SI_GND SI-Ground input.
Ground connection for SI comparator resistor divider. Depending on
SI_ENABLE this input is switched to high impedance or low ohmic to GND.
7SI
Sense comparator input.
Input of the low-battery comparator. This input is compared to an internal
1.25V reference where SO gives the result of the comparison. Can be
used for any comparison, not necessarily as battery sense.
8RD
Reset delay input.
Connect a ceramic capacitor to GND for power on reset delay time
adjustment.
