Data Sheet
71
Rev. 1.0, 2010-02-09
TLE8242-2
Functional Description and Electrical Characteristics
Time out
1
DATA
Current Profile Timeout (RESET Value = 0)
Reset when this register is read.
Set when the programmable time-out timer expires before the Current
Profile Detection sequence has completed.
PASS
0
DATA
Passed Since Last Read (RESET Value = 0)
Reset when this register is read.
Set when the Current Profile Detection sequence has completed
before the programmed time-out timer expired and before the gate is
turned off.
Table 7
Interpretation of bits 2 to 0
Detect Interrupt Bit
Current Profile Timeout
Passed Since Last Read Meaning
0
A current profile sequence
has not completed since
the last read of this register
X
1
At least one current profile
sequence has completed
successfully since the last
read of this register
X
1
X
At least one time out failure
has occurred since the last
read of this register
1
X
At least one detect
interrupt failure has
occurred since the last
read of this register.
Field
Bits
Type
Description
