SLAS553A – NOVEMBER 2008 – REVISED SEPTEMBER 2009...................................................................................................................................... www.ti.com
The remaining page 4 registers are either reserved registers or are used for setting coefficients for the various
filters in the processing blocks. Reserved registers should not be written to.
The filter coefficient registers are arranged in pairs, with two adjacent 8-bit registers containing the 16-bit
coefficient for a single filter. The 16-bit integer contained in the MSB and LSB registers for a coefficient are
interpreted as a 2s-complement integer, with possible values ranging from –32,768 to 32,767. When
programming any coefficient value for a filter, the MSB register should always be written first, immediately
followed by the LSB register. Even if only the MSB or LSB portion of the coefficient changes, both registers
should be written in this sequence. Table 13 is a list of the page 4 registers, excepting the previously described
register 0.
Table 13. Page 4 Registers
REGISTER
RESET VALUE
REGISTER NAME
NUMBER
1
XXXX XXXX
Reserved. Do not write to this register.
Coefficient N0(15:8) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
2
0000 0001
C1(15:8) of ADC miniDSP
Coefficient N0(7:0) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
3
0001 0111
C1(7:0) of ADC miniDSP
Coefficient N1(15:8) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
4
0000 0001
C2(15:8) of ADC miniDSP
Coefficient N1(7:0) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
5
0001 0111
C2(7:0) of ADC miniDSP
Coefficient D1(15:8) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
6
0111 1101
C3(15:8) of ADC miniDSP
Coefficient D1(7:0) for AGC LPF (first-order IIR) used as averager to detect level or Coefficient
7
1101 0011
C3(7:0) of ADC miniDSP
Coefficient N0(15:8) for Left ADC programmable first-order IIR or Coefficient C4(15:8) of ADC
8
0111 1111
miniDSP
Coefficient N0(7:0) for Left ADC programmable first-order IIR or Coefficient C4(7:0) of ADC
9
1111 1111
miniDSP
Coefficient N1(15:8) for Left ADC programmable first-order IIR or Coefficient C5(15:8) of ADC
10
0000 0000
miniDSP
Coefficient N1(7:0) for Left ADC programmable first-order IIR or Coefficient C5(7:0) of ADC
11
0000 0000
miniDSP
Coefficient D1(15:8) for Left ADC programmable first-order IIR or Coefficient C6(15:8) of ADC
12
0000 0000
miniDSP
Coefficient D1(7:0) for Left ADC programmable first-order IIR or Coefficient C6(7:0) of ADC
13
0000 0000
miniDSP
Coefficient N0(15:8) for Left ADC Biquad A or Coefficient FIR0(15:8) for ADC FIR Filter or
14
0111 1111
Coefficient C7(15:8) of ADC miniDSP
Coefficient N0(7:0) for Left ADC Biquad A or Coefficient FIR0(7:0) for ADC FIR Filter or Coefficient
15
1111 1111
C7(7:0) of ADC miniDSP
Coefficient N1(15:8) for Left ADC Biquad A or Coefficient FIR1(15:8) for ADC FIR Filter or
16
0000 0000
Coefficient C8(15:8) of ADC miniDSP
Coefficient N1(7:0) for Left ADC Biquad A or Coefficient FIR1(7:0) for ADC FIR Filter or Coefficient
17
0000 0000
C8(7:0) of ADC miniDSP
Coefficient N2(15:8) for Left ADC Biquad A or Coefficient FIR2(15:8) for ADC FIR Filter or
18
0000 0000
Coefficient C9(15:8) of ADC miniDSP
Coefficient N2(7:0) for Left ADC Biquad A or Coefficient FIR2(7:0) for ADC FIR Filter or Coefficient
19
0000 0000
C9(7:0) of ADC miniDSP
Coefficient D1(15:8) for Left ADC Biquad A or Coefficient FIR3(15:8) for ADC FIR Filter or
20
0000 0000
Coefficient C10(15:8) of ADC miniDSP
Coefficient D1(7:0) for Left ADC Biquad A or Coefficient FIR3(7:0) for ADC FIR Filter or Coefficient
21
0000 0000
C10(7:0) of ADC miniDSP
Coefficient D2(15:8) for Left ADC Biquad A or Coefficient FIR4(15:8) for ADC FIR Filter or
22
0000 0000
Coefficient C11(15:8) of ADC miniDSP
68
Copyright 2008–2009, Texas Instruments Incorporated
Product Folder Link(s) :TLV320ADC3101
