Page 0 / Register 60 (0x3C): DAC Processing Block Selection
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D5
R/W
000
Reserved. Write only default value.
D4–D0
R/W
00 0001
0 0000: Reserved. Do not use.
0 0001: DAC Signal Processing Block PRB_P1
0 0010: DAC Signal Processing Block PRB_P2
0 0011: DAC Signal Processing Block PRB_P3
0 0100: DAC Signal Processing Block PRB_P4
...
1 1000: DAC Signal Processing Block PRB_P24
1 1001: DAC Signal Processing Block PRB_P25
1 1010–1 1111: Reserved. Do not use.
Page 0 / Register 61–62: Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
XXXX XXXX
Reserved. Do not write.
Page 0 / Register 63 (0x3F): DAC Data-Path Setup
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R/W
0
0: Left-channel DAC is powered down.
1: Left-channel DAC is powered up.
D6
R/W
0
0: Right-channel DAC is powered down.
1: Right-channel DAC is powered up.
D5–D4
R/W
01
00: Left-channel DAC data path = off
01: Left-channel DAC data path = left data
10: Left-channel DAC data path = right data
11: Left-channel DAC data path = left-channel and right-channel data ((L + R)/2)
D3–D2
R/W
01
00: Right-channel DAC data path = off
01: Right-channel DAC data path = right data
10: Right-channel DAC data path = left data
11: Right-channel DAC data path = left-channel and right-channel data ((L + R)/2)
D1–D0
R/W
00
00: DAC channel volume control soft-stepping is enabled for one step per sample period.
01: DAC channel volume control soft-stepping is enabled for one step per two sample periods.
10: DAC channel volume control soft-stepping is disabled.
11: Reserved. Do not write this sequence to these bits.
Page 0 / Register 64 (0x40): DAC VOLUME CONTROL
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D4
R/W
0000
Reserved. Write only zeros to these bits.
D3
R/W
1
0: Left-channel DAC not muted
1: Left-channel DAC muted
D2
R/W
1
0: Right-channel DAC not muted
1: Right-channel DAC muted
D1–D0
R/W
00
00: Left and right channels have independent volume control.
01: Left-channel volume control Is the programmed value of right-channel volume control.
10: Right-channel volume control is the programmed value of left-channel volume control.
11: Same as 00
Copyright 2010, Texas Instruments Incorporated
REGISTER MAP
73
Product Folder Link(s): TLV320DAC3101
