www.ti.com
ABSOLUTE MAXIMUM RATINGS
DISSIPATION RATING TABLE
(1)
TPA6021A4
SLOS465 – JUNE 2005
These devices have limited built-in ESD protection. The leads should be shorted together or the device
placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
AVAILABLE OPTIONS
PACKAGE
TA
20-PIN PDIP (N)
–40
°C to 85°C
TPA6021A4N
over operating free-air temperature range (unless otherwise noted)(1)
UNIT
VSS
Supply voltage, VDD, PVDD
–0.3 V to 6 V
VI
Input voltage, RIN+, RIN-, LIN+,LIN-
–0.3 V to VDD+0.3 V
Continuous total power dissipation
See Dissipation Rating Table
TA
Operating free-air temperature range
–40
°C to 85°C
TJ
Operating junction temperature range
–40
°C to 150°C
Tstg
Storage temperature range
–65
°C to 85°C
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds
260
°C
(1)
Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under "recommended operating
conditions" is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
TA = 25°C
DERATING FACTOR
TA = 70°C
TA = 85°C
PACKAGE
POWER RATING
ABOVE TA = 25°C
POWER RATING
N
1.8 W
14.5 mW/
°C
1.16 W
0.94 W
(1)
All characterization is done using an external heatsink with
θ
SA= 25°C/W. The resulting derating factor
is 22.2 mW/
°C.
2
