TPA6101A2
50mW ULTRALOW VOLTAGE, FIXEDGAIN STEREO HEADPHONE
AUDIO POWER AMPLIFIER
2
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
AVAILABLE OPTIONS
TA
PACKAGED DEVICE
MSOP
BGA
TA
SMALL OUTLINE (D)
MSOP (DGK)
BGA (ZQY)
MSOP
SYMBOLIZATION
BGA
SYMBOLIZATION
40
°C to 85°C
TPA6101A2D
TPA6101A2DGK
TPA6101A2ZQYR
AJM
AAQI
Terminal Functions
TERMINAL
NO.
I/O
DESCRIPTION
NAME
D,
DGK
ZQY
I/O
DESCRIPTION
BYPASS
1
A1
I
Tap to voltage divider for internal mid-supply bias supply. BYPASS is set at VDD/4. Connect to a 0.1-F
to 1-
F low-ESR capacitor for best performance.
GND
2
B1
–
GND is the ground connection.
IN1
8
A4
I
IN1 is the inverting input for channel 1.
IN2
4
D1
I
IN2 is the inverting input for channel 2.
SHUTDOWN
3
C1
I
Active-low input. When held low, the device is placed in a low-supply-current mode.
VDD
6
C4
–
VDD is the supply voltage terminal.
VO1
7
B4
O
VO1 is the audio output for channel 1.
VO2
5
D4
O
VO2 is the audio output for channel 2.
absolute maximum ratings over operating free-air temperature (unless otherwise noted)
Supply voltage, VDD
4 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage, VI
0.3 V to VDD + 0.3 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous total power dissipation
Internally Limited
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating junction temperature range, TJ
40
°C to 150°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, Tstg
65
°C to 150°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds
260
°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
DISSIPATION RATING TABLE
PACKAGE
TA ≤ 25°C
POWER RATING
DERATING FACTOR
ABOVE TA = 25°C
TA = 70°C
POWER RATING
TA = 85°C
POWER RATING
D
710 mW
5.68 mW/
°C
454 mW
369 mW
DGK
469 mW
3.75 mW/
°C
300 mW
244 mW
ZQY
2 W
17.1 mW/
°C
1.28 W
1.04 W
recommended operating conditions
MIN
MAX
UNIT
Supply voltage, VDD
1.6
3.6
V
High-level input voltage, VIH (SHUTDOWN)
0.6 VDD
V
Low-level input voltage, VIL (SHUTDOWN)
0.25 VDD
V
Operating free-air temperature, TA
–40
85
°C
