TPA6101A2
50-mW ULTRALOW-VOLTAGE, FIXED-GAIN STEREO HEADPHONE
AUDIO POWER AMPLIFIER
SLOS331A – AUGUST 2000 – REVISED NOVEMBER 2000
4
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
dc electrical characteristics at TA = 25°C, VDD = 1.6 V
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
PSRR
Power supply rejection ratio
VDD = 1.4 V to 1.8 V
80
dB
IDD
Supply current
0.65
1.2
mA
IDD(SD)
Supply current in SHUTDOWN mode
50
250
nA
|IIH|
High-level input current (SHUTDOWN)
VDD = 1.6 V, VI = VDD
1
A
|IIL|
Low-level input current (SHUTDOWN)
VDD = 1.6 V, VI = 0 V
1
A
ZI
Input impedance
80
k
ac operating characteristics, VDD = 1.6 V, TA = 25°C, RL = 16
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
G
Gain
2
dB
PO
Output power (each channel)
THD
≤ 0.5%,
f = 1 kHz
10
mW
THD+N
Total harmonic distortion + noise
PO = 9.5 mW,
20–20 kHz
0.06%
BOM
Maximum output power BW
THD < 1%
> 20
kHz
kSVR
Supply ripple rejection
f = 1 kHz
47
dB
SNR
Signal-to-noise ratio
PO = 10 mW
82
dB
Vn
Noise output voltage (no noise weighting filter)
32
V(rms)
ac operating characteristics, VDD = 1.6 V, TA = 25°C, RL = 32
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
G
Gain
2
dB
PO
Output power (each channel)
THD
≤ 0.5%,
f = 1 kHz
7.5
mW
THD+N
Total harmonic distortion + noise
PO = 6.5 mW,
20–20 kHz
0.05%
BOM
Maximum output power BW
THD < 1%
>20
kHz
kSVR
Supply ripple rejection
f = 1 kHz
47
dB
SNR
Signal-to-noise ratio
PO = 7.5 mW
84
dB
Vn
Noise output voltage (no noise weighting filter)
32
V(rms)
