0
100
200
300
400
500
600
700
800
900
1000
1100
1200
1300
1400
1500
1600
1700
1800
15
20
25
30
35
40
45
50
55
60
65
70
75
80
R
-k
ILIM
W
Current-LimitThreshold-mA
IOC(max)
IOC(typ)
IOC(min)
IOS(min)
APPLICATION 1: DESIGNING ABOVE A MINIMUM CURRENT-LIMIT
APPLICATION 2: DESIGNING BELOW A MAXIMUM CURRENT-LIMIT
SLVS736B – FEBRUARY 2008 – REVISED NOVEMBER 2008 ........................................................................................................................................ www.ti.com
Figure 21. Current-Limit Threshold Vs.RILIM
Some applications require that current-limiting cannot occur below a certain threshold. For this example, assume
that 1 A must be delivered to the load so that the minimum desired current-limit threshold is 1000 mA. Use the
I
OS(min) (mA) = 1000 mA
I
OS(min) (mA) = (39700 V) / ILIM (k))
1.342
R
ILIM (k) = [(39700 V) / (IOS(min) (mA))]
1/1.342
R
ILIM = 15.54 k
Select the closest 1% resistor less than the calculated value: RILIM = 15.4 k. This sets the minimum current-limit
threshold at 1 A . Use the IOC equations, Figure 21, and the previously calculated value for RILIM to calculate the
maximum resulting current-limit threshold.
R
ILIM = 15.4 k
I
OC(max) (mA) = (24500 V) / ILIM (k))
0.975
I
OC(max) (mA) = (24500 V) / (15 (k))
0.975
I
OC(max) = 1703 mA
The resulting maximum current-limit threshold is 1.7 A with a 15.4 k
resistor.
Some applications require that current-limiting must occur below a certain threshold. For this example, assume
that the desired upper current-limit threshold must be below 1.25 A to protect an up-stream power supply. Use
I
OC(max) (mA) = 1250 mA
I
OC(max) (mA) = (24500 V) / ILIM (k))
0.975
R
ILIM (k) = [(24500 V) / (IOC(max) (mA))]
1/0.975
R
ILIM = 21.15 k
18
Copyright 2008, Texas Instruments Incorporated
