TPS5602, Dual, Wide Input Voltage Synchronous Buck Controller for DSPs
Device Status: Active
> Description
> Features
> Datasheets
> Pricing/Samples/Availability
> Application Notes
> Development Tools
> Applications
Parameter Name
TPS5602
Pin Count
30
Frequency (max) (kHz)
500
Vref tol (%)
2
Output Voltage (max) (V)
24
Output Voltage (min) (V)
1.2
Operating Supply (max) (V)
25
Operating Supply (min) (V)
4.5
Regulated Outputs (#)
2
Operating Supply Current (mA) 0.8
Shutdown Supply Current (uA) 1
Shutdown or Enable Input
Yes
Current Limit
Yes
Power Limit
No
Output Current (mA)
1500
High Side N-Channel Driver
Yes
Light Load Efficiency Features No
Description
The TPS5602 is a dual-channel synchronous buck switch-mode power supply controller
featuring very fast feedback control and minimized component count. By using the
hysteretic control method, it is ideal for high-transient current applications, such as 'C6000
and multiple 'C54x DSPs. The TPS5602 is designed specifically for DSP applications that
require high efficiency. Since both channels are independent, the up and down power
sequencing can be easily achieved by properly setting the standby pins. The wide input
voltage and adjustable output voltage make the TPS5602 suitable for many applications.
