TPS60100
REGULATED 3.3 V 200mA LOW NOISE
CHARGE PUMP DC/DC CONVERTER
SLVS213C MAY 1999 REVISED AUGUST 2008
17
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
APPLICATION INFORMATION
For the TPS60100, the smallest board space size can be achieved using Sprague’s 595D-series tantalum
capacitors for input and output. However, with the trend towards high capacitance ceramic capacitors in smaller
size packages, these type of capacitors might become competitive in size soon.
Table 5. Recommended Capacitors
MANUFACTURER
PART NUMBER
CAPACITANCE
TYPE
Taiyo Yuden
LMK212BJ105KGT
LMK212BJ225MGT
JMK316BJ106MLT
LMK432BJ226MMT
1
F
2.2
F
10
F
22
F
Ceramic
AVX
0805ZC105KAT2A
1206ZC225KAT2A
TPSC106025R0500
TPSC226016R0375
1
F
2.2
F
10
F
22
F
Ceramic
Tantalum
Sprague
595D106X0010A2T
595D226X06R3A2T
595D226X06R3B2T
595D226X0020C2T
10
F
22
F
22
F
22
F
Tantalum
Kemet
T494C106M010AS
T494C226M010AS
10
F
22
F
Tantalum
Table 6 lists the manufacturers of recommended capacitors. In most applications surface-mount tantalum
capacitors will be the right choice. However, ceramic capacitors will provide the lowest output voltage ripple due
to their typically lower ESR.
Table 6. Recommended Capacitor Manufacturers
MANUFACTURER
CAPACITOR TYPE
INTERNET
Taiyo Yuden
X7R/X5R ceramic
www.tyuden.com
AVX
X7R/X5R ceramic
TPSseries tantalum
www.avxcorp.com
Sprague
595Dseries tantalum
593Dseries tantalum
www.vishay.com
Kemet
T494series tantalum
www.kemet.com
power dissipation
The power dissipated in the TPS60100 depends on output current and is approximated by:
P
DISS + IO
2V
IN
* V
O for IQ tt IO
PDISS must be less than that allowed by the package rating. See the ratings for 20-PowerPAD package
power-dissipation limits and deratings.
