www.ti.com
ABSOLUTE MAXIMUM RATINGS
DISSIPATION RATINGS
RECOMMENDED OPERATING CONDITIONS
SLVS737 – FEBRUARY 2007
ORDERING INFORMATION(1)
TA
PART
DEFAULT OUTPUT
OUTPUT
QFN (1)
ORDERING
PACKAGE
NUMBER
VOLTAGE (2)
CURRENT
PACKAGE
MARKING
(1)
OUT1
800mA
–40
°C to 85°C
TPS62410
Adjustable
DRC
TPS62410DRC
CAT
OUT2
800mA
(1)
For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
Web site at www.ti.com.
over operating free-air temperature range (unless otherwise noted)(1)
VALUE
UNIT
Input voltage range on VIN(2)
–0.3 to 7
V
Voltage range on EN, MODE/DATA, DEF_1
–0.3 to VIN +0.3, ≤7
V
Maximum Current into MODE/DATA
500
A
Voltage on SW1, SW2
–0.3 to 7
V
Voltage on ADJ2, FB1
–0.3 to VIN +0.3, ≤7
V
ESD rating(3)
HBM Human body nodel
2
kV
Charge device model
1
kV
Machine model
200
V
TJ(max) Maximum junction temperature
150
°C
TA
Operating ambient temperature range
–40 to 85
°C
Tstg
Storage temperature range
–65 to 150
°C
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute–maximum–rated conditions for extended periods may affect device reliability.
(2)
All voltage values are with respect to network ground terminal.
(3)
The human body model is a 100pF capacitor discharged through a 1.5k
resistor into each pin. The machine model is a 200pF
capacitor discharged directly into each pin.
PACKAGE
RθJA
POWER RATING FOR TA≤ 25°C
DERATING FACTOR ABOVE TA = 25°C
DRC
49
°C/W
2050mW
21mW/
°C
over operating free-air temperature range (unless otherwise noted)
MIN
NOM
MAX
UNIT
VIN
Supply voltage
2.5
6
V
Output voltage range for adjustable voltage
0.6
VIN
V
TA
Operating ambient temperature
-40
85
°C
TJ
Operating junction temperature
-40
125
°C
2
