SLVS927C – MARCH 2009 – REVISED MAY 2010
www.ti.com
TERMINAL FUNCTIONS (continued)
TERMINAL
I/O
DESCRIPTION
NAME
NO.
Input signal indicating default VDCDC1 voltage, 0 = 1.2 V, 1 = 1.6 V DEFDCDC1 can also be
DEFDCDC1
10
I
connected to a resistor divider between VDCDC1 and GND, if the output voltage of the DCDC1
converter is set in a range from 0.6 V to VINDCDC1 V.
Input signal indicating default VDCDC2 voltage, 0 = 1.8 V, 1 = 3.3 V DEFDCDC2 can also be
DEFDCDC2
32
I
connected to a resistor divider between VDCDC2 and GND, if the output voltage of the DCDC2
converter is set in a range from 0.6 V to VINDCDC2 V.
Input signal indicating default VDCDC3 voltage, 0 = 1.8 V, 1 = 3.3 V DEFDCDC3 can also be
DEFDCDC3
1
I
connected to a resistor divider between VDCDC3 and GND, if the output voltage of the DCDC3
converter is set in a range from 0.6 V to VINDCDC3 V.
DCDC1_EN
25
I
VDCDC1 enable pin. A logic high enables the regulator, a logic low disables the regulator.
DCDC2_EN
24
I
VDCDC2 enable pin. A logic high enables the regulator, a logic low disables the regulator.
DCDC3_EN
23
I
VDCDC3 enable pin. A logic high enables the regulator, a logic low disables the regulator.
LDO REGULATOR SECTION
VINLDO
19
I
Input voltage for LDO1 and LDO2
VLDO1
20
O
Output voltage of LDO1
VLDO2
18
O
Output voltage of LDO2
LDO_EN
22
I
Enable input for LDO1 and LDO2. A Logic high enables the LDOs, a logic low disables the LDOs.
VBACKUP
15
I
Connect the backup battery to this input pin.
VRTC
16
O
Output voltage of the LDO/switch for the real time clock.
VSYSIN
14
I
Input of system voltage for VRTC switch.
DEFLD01
12
I
Digital input. DEFLD01 sets the default output voltage of LDO1 and LDO2.
DEFLD02
13
I
Digital input. DEFLD02 sets the default output voltage of LDO1 and LDO2.
CONTROL AND I2C SECTION
HOT_RESET
11
I
Push button input that reboots or wakes up the processor via RESPWRON output pin.
TRESPWRON
26
I
Connect the timing capacitor to TRESPWRON to set the reset delay time: 1 nF
→ 100 ms.
RESPWRON
27
O
Open drain system reset output.
PWRFAIL
31
O
Open drain output. Active low when PWRFAIL comparator indicates low VBAT condition.
LOW_BAT
21
O
Open drain output of LOW_BAT comparator.
INT
28
O
Open drain output
SCLK
30
I
Serial interface clock line
SDAT
29
I/O
Serial interface data/address
PWRFAIL_SNS
38
I
Input for the comparator driving the PWRFAIL output.
LOWBAT_SNS
39
I
Input for the comparator driving the LOW_BAT output.
12
Copyright 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TPS65023-Q1
