TS4975
Electrical Characteristics
7/36
Crosstalk
Channel Separation
RL =32, AV = 2dB with Single-ended
F= 1kHZ, Pout = 10mW
103
dB
RL =32, AV = 2dB with Single-ended
F = 20Hz to 20kHz, Pout = 10mW
75
RL =32, AV = 2dB with Phantom Ground,
F= 1kHZ, Pout = 10mW
69
RL =32, AV = 2dB with Phantom Ground,
F = 20Hz to 20kHz, Pout = 10mW
69
SNR
Signal to Noise Ratio
A-Weighted
AV = 2dB, RL =32, Pout =12mW
Single-Ended
88
dB
AV = 2dB, RL =32, Pout =12mW
Phantom Ground
88
ONoise
Output Noise Voltage,
A-Weighted
AV = 2dB, Single-ended
23
Vrms
AV = 2dB, Phantom Ground
23
G
Digital Gain Range
In1 & In2 to Out1 & Out2
-34
+18
dB
Digital Gain Stepsize
4
dB
Gain Error Tolerance
-1
+1
dB
Zin
In1 & In2 Input
Impedance
All gain settings
25.5
30
34.5
k
twu
Wake up time
Cb = 1F
110
180
ms
tws
Standby time
1
s
1.
Dynamic measurements - 20*log(rms(Vout)/rms(Vripple)). Vripple is an added sinus signal to VCC @ F = 217Hz
Table 5.
VCC = +2.5 V, GND = 0V, Tamb = 25°C (unless otherwise specified)
Symbol
Parameter
Conditions
Min.
Typ.
Max.
Unit
