TS5A3153
1 W SPDT ANALOG SWITCH
5V/3.3V SINGLECHANNEL 2:1 MULTIPLEXER/DEMULTIPLEXER
SCDS215 – OCTOBER 2005
www.ti.com
16
V+
GND
VBIAS
VI
VI = V+ or GND
VBIAS = V+ or GND
Capacitance is measured at NC,
NO, COM, and IN inputs during
ON and OFF conditions.
Capacitance
Meter
VCOM
VNO
VNC
COM
NO
NC
IN or EN
Figure 16. Capacitance (CI, CCOM(OFF), CCOM(ON), CNC(OFF), CNO(OFF), CNC(ON), CNO(ON))
CL(2)
RL
VCOM
V+
GND
NC or NO VNC or VNO
VI
NC or NO
COM
Logic
Input(1)
V+
VCOM
50
RL
CL
35 pF
tON
TEST
V+
50
35 pF
tOFF
50%
tON
tOFF
50%
90%
Logic
Input
(VI)
V+
Switch
Output
(VNC orVNO)
0
CL(2)
RL
IN or EN
(1) All input pulses are supplied by generators having the following characteristics: PRR ≤ 10 MHz, ZO = 50 , tr < 5 ns, tf < 5 ns.
(2) CL includes probe and jig capacitance.
Figure 17. Turn-On (tON) and Turn-Off Time (tOFF)
V+
GND
NC or NO
IN
VNC orVNO
VI
NC or NO
COM
VCOM
CL(2)
RL
tBBM
50%
90%
VNC or VNO = V+
RL = 50
CL = 35 pF
Logic
Input(1)
Logic
Input
(VI)
Switch
Output
(VCOM)
V+
0
(1) All input pulses are supplied by generators having the following characteristics: PRR ≤ 10 MHz, ZO = 50 , tr < 5 ns, tf < 5 ns.
(2) CL includes probe and jig capacitance.
Figure 18. Break-Before-Make Time (tBBM)
