TS5A3166
0.9 W SPST ANALOG SWITCH
SCDS186 FEBRUARY 2005
www.ti.com
2
ORDERING INFORMATION
TA
PACKAGE(1)
ORDERABLE PART NUMBER
TOP-SIDE MARKING(2)
NanoStar
WCSP (DSBGA)
0.23-mm Large Bump YEP
Tape and reel
TS5A3166YEPR
40
°C to 85°C
NanoFree
WCSP (DSBGA)
0.23-mm Large Bump YZP (Pb-free)
Tape and reel
TS5A3166YZPR
SOT (SOT-23) DBV
Tape and reel
TS5A3166DBVR
JAS_
SOT (SC-70) DCK
Tape and reel
TS5A3166DCKR
JF_
(1) Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines are available at www.ti.com/sc/package.
(2) DBV/DCK: The actual top-side marking has one additional character that designates the assembly/test site.
YEP/YZP: The actual top-side marking has three preceding characters to denote year, month, and sequence code, and one following character
to designate the assembly/test site. Pin 1 identifier indicates solder-bump composition (1 = SnPb,
= Pb-free).
Absolute Minimum and Maximum Ratings(1)(2)
over operating free-air temperature range (unless otherwise noted)
MIN
MAX
UNIT
V+
Supply voltage range(3)
0.5
6.5
V
VNO
VCOM
Analog voltage range(3)(4)(5)
0.5
V+ + 0.5
V
IK
Analog port diode current
VNO, VCOM < 0
50
mA
INO
On-state switch current
VNO, VCOM = 0 to V+
200
mA
INO
ICOM
On-state peak switch current(6)
VNO, VCOM = 0 to V+
400
mA
VI
Digital input voltage range(3)(4)
0.5
6.5
V
IIK
Digital input clamp current
VI < 0
50
mA
I+
Continuous current through V+
100
mA
IGND
Continuous current through GND
100
mA
(7)
DBV package
206
θJA
Package thermal impedance(7)
DCK package
252
°C/W
θJA
Package thermal impedance(7)
YEP/YZP package
132
C/W
Tstg
Storage temperature range
65
150
°C
(1) Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade
device reliability. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those specified
is not implied.
(2) The algebraic convention, whereby the most negative value is a minimum and the most positive value is a maximum
(3) All voltages are with respect to ground, unless otherwise specified.
(4) The input and output voltage ratings may be exceeded if the input and output clamp-current ratings are observed.
(5) This value is limited to 5.5 V maximum.
(6) Pulse at 1-ms duration < 10% duty cycle
(7) The package thermal impedance is calculated in accordance with JESD 51-7.
