www.ti.com
TVP5154
4-CHANNEL LOW-POWER PAL/NTSC/SECAM VIDEO DECODER
WITH INDEPENDENT SCALERS AND FAST LOCK
SLES163A – MARCH 2006 – REVISED JULY 2006
Table 9-1. Direct Register Summary (continued)
REGISTER FUNCTION
ADDRESS
DEFAULT
R/W(1)
Ancillary SAV/EAV control
17h
52h
R/W
Vertical blanking start
18h
00h
R/W
Vertical blanking stop
19h
00h
R/W
Chrominance processing control #1
1Ah
0Ch
R/W
Chrominance processing control #2
1Bh
14h
R/W
Interrupt reset register B
1Ch
00h
R/W
Interrupt enable register B
1Dh
00h
R/W
Interrupt configuration register B
1Eh
00h
R/W
Output control
1Fh
00h
R/W
Reserved
20h
I2C indirect registers
21h–24h
00h
R/W
AVID start/control for scaled data
25h–26h
00h
R/W
Reserved
27h
Video standard
28h
00h
R/W
AVID stop for scaled data
29h–2Ah
00h
R/W
Reserved
2Bh
Cb gain factor
2Ch
R
Cr gain factor
2Dh
R
Reserved
2Eh–2Fh
656 Revision Select
30
00h
R/W
Reserved
31h–7Fh
MSB of device ID
80h
51h
R
LSB of device ID
81h
54h
R
ROM major version
82h
02h
R
ROM minor version
83h
00h
R
Vertical line count MSB
84h
R
Vertical line count LSB
85h
R
Interrupt status register B
86h
R
Interrupt active register B
87h
R
Status register #1
88h
R
Status register #2
89h
R
Status register #3
8Ah
R
Status register #4
8Bh
R
Status register #5
8Ch
R
Reserved
8Dh–8Fh
Closed caption data registers
90h–93h
R
WSS data registers
94h–99h
R
VPS data registers
9Ah–A6h
R
VITC data registers
A7h–AFh
R
VBI FIFO read data
B0h
R
Teletext filter 1
B1h–B5h
00h
R/W
Teletext filter 2
B6h–BAh
00h
R/W
Teletext filter enable
BBh
00h
R/W
Reserved
BCh–BFh
Interrupt status register A
C0h
00h
R/W
Interrupt enable register A
C1h
00h
R/W
Interrupt configuration
C2h
04h
R/W
Internal Control Registers
21
