SLES243E
– JULY 2009 – REVISED MARCH 2011
Table 3-13. Bit Field Definition of 4-Byte Start Code for Active Video Line (continued)
BIT
NAME
FUNCTION
Two MSBs of 9-bit Line ID, active video line number. Line counter resets to 000h at beginning of active
[17:16]
LN_ID[8:7]
video (i.e., resets once per field). During the vertical blanking interval, the line counter may either continue
counting or hold the terminal count determined at the end of active video.
15
~LN_ID[6]
Always set to the complement of bit 14 (LN_ID[6]).
Seven LSBs of 9-bit Line ID, active video line number. Line counter resets to 000h at beginning of active
[14:8]
LN_ID[6:0]
video (i.e., resets once per field). During the vertical blanking interval, the line counter may either continue
counting or hold the terminal count determined at the end of active video.
7
1
Always set to 1.
F-bit
6
F
0: First field of frame
1: Second field of frame
V-bit
5
V
0: when not in vertical blanking
1: during vertical blanking
H-bit. Always set to 0.
4
H
0: SAV
1: EAV (never used)
3
P3
P3 = V XOR H, Protection bits used for error detection/correction
2
P2
P2 = F XOR H, Protection bits used for error detection/correction
1
P1
P1 = F XOR V, Protection bits used for error detection/correction
0
P0
P0 = F XOR V XOR H, Protection bits used for error detection/correction
NOTE
For line-interleaved output mode, if none of video decoder channels has the data ready at a
given time, TVP5158 outputs the dummy line until any one of video decoder channels is
ready to output a line. The backend chip needs to keep only the active video line and ignore
the dummy line.
The start code of the dummy line is different with active video line. Table 3-14 shows the bit assignment
and field definition of 4-Byte start code for the Dummy Line.
Table 3-14. Bit Assignment of 4-Byte Start Code for the Dummy Line
BYTE
7
6
5
4
3
2
1
0
SC[3]
0
1
SC[2]
0
1
SC[1]
0
1
SC[0]
0
1
NOTE
The Dummy Line can be distinguished from active video line by looking at the MSB of byte
SC[0].
Copyright
2009–2011, Texas Instruments Incorporated
Functional Description
31
