參數資料
| 型號： | TVP5200PZP |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 消費家電 |
| 英文描述： | SPECIALTY CONSUMER CIRCUIT, PQFP100 |
| 封裝： | POWER, PLASTIC, TQFP-100 |
| 文件頁數： | 2/11頁 |
| 文件大小： | 152K |
| 代理商： | TVP5200PZP |
TEXAS
TVP5200
INSTRUMENTS
All-Format Analog Video Signal Processor
SLES037
PRODUCT PREVIEW 8/21/02
1-9
Product Preview documents contain information on products
in the formative or design phase of development. Characteristic data
and other specifications are design goals. Texas Insruments reserves
the right to change or discontinue the products without prior notice.
RSTINB
35
I
Reset input, active low.
OEB
39
I
Active low output enable for the 30-bit video output. When OEB is set logic 0,
the 30-bit output is placed in a high-impedance state. Allows multiplexing the
output of the TVP5200 with the output of another front end device e.g. a DVI
receiver.
FASTSWITCH
40
I
Fast-Switch. Switching between synchronous component video (YPbPr / RGB)
and composite video inputs, or supporting selective color space conversion on
one of two externally switched synchronous component video sources.
GLCO
92
O
Genlock Control Output (GLCO). 2 genlock data formats are available: T.I.
formats and Real Time Control (RTC) format.
GPCL
93
I/O
Programmable general purpose I/O.
INTREQ
94
I/O
Interrupt request.
SDA
37
I/O
I
2C Data Bus.
SCL
36
I
2C Clock input.
Power Supplies
NSUB
95
I
Substrate ground. Connect to analog ground.
CH1_A33GND
CH2_A33GND
CH3_A33GND
CH4_A33GND
1
4
19
22
I
Analog 3.3V return.
CH1_A33VDD
CH2_A33VDD
CH3_A33VDD
CH4_A33VDD
2
3
20
21
I
Analog power. Connect to 3.3V.
CH1_A18GND
CH2_A18GND
CH3_A18GND
CH4_A18GND
97
9
14
26
I
Analog 1.8V return.
CH1_A18VDD
CH2_A18VDD
CH3_A18VDD
CH4_A18VDD
96
10
13
27
I
Analog power. Connect to 1.8V.
A18GND_REF
12
I
Analog 1.8V return.
A18VDD_REF
11
I
Analog power for reference 1.8V.
PLL_A18GND
31
I
Analog power return.
PLL_A18VDD
34
I
Analog power. Connect to 1.8V.
DGND
42,56,70,84
I
Digital return.
DVDD
41,55,69,83
I
Digital power. Connect to 1.8V.
IOGND
49,63,77
I
Digital power return.
IOVDD
48,62,76
I
Digital power. Connect to 3.3V or less for reduced noise.
Sync Signals
HSYNC
29
I
Horizontal Sync Input (for modes with dedicated Hsync) or digital Composite
