MOS INTEGRATED CIRCUIT
μ
PD16454A
DATA SHEET
Document No. IC-3362A (2nd edition)
(0. D. No. IC-8800)
Date Published March 1997 P
Printed in Japan
1994
The
μ
PD16454A is a single-chip controller/driver for dot matrix LCD, enabling the display of up to 48
alphanumerical and kana characters and symbols (24 characters
×
2 lines) each of which is composed of 5
×
7 dots.
On-chip charge pump-type DC/DC converter that enables the
μ
PD16454A to operate on a single 5-V power supply
and the chip design aiming at tape carrier package (TCP) mounting make the
μ
PD16454A ideal for portable
equipment and all kinds of data terminals for which downsizing is an important consideration.
FEATURES
5
×
7 dot matrix LCD display controller/driver
24 characters
×
2 lines, 1/14 duty display
Interface with CPU 4 bits wise
On-chip ROM and RAM
Display data RAM (8
×
48 bits)
Character generator RAM (8 user-defined characters; 5
×
7
×
8 bits)
Character generator ROM (160 characters; 5
×
7
×
160 bits)
On-chip LCD driver
120 segment signals
14 common signals
Single 5-V power supply
Doubling DC/DC booster generating 10 V for driving LCDs
Total power dissipation: 2 mA max.
On-chip temperature compensation circuit
TCP mounting enabled
ORDERING INFORMATION
Part number
Available as
μ
PD16454AN-XXX
TCP (TAB)
μ
PD16454AP
Chip
TPC formats are created on a custom-made basis. For additional information, contact an NEC sales
representative.
For purchases of chips only, additional documents on quality are required. Contact an NEC sales representative.
